Intergraph InterServe 80 SL System Setup page 23

Note the following about labeling of RAID disk drives and non-RAID disk drives.
u
For a RAID system, three disk drives, with pre-installed operating system and system
software, are standard. These drives, called boot drives, are labeled with specific adapter,
channel, and identification number, as follows:
4 GB 0
ADP CH
4 GB 0
ADP CH
4 GB 0
ADP CH
RAID Drive 0 installs into the rightmost slot of the disk drive section. RAID Drive 1
installs to the left of Drive 0, and RAID Drive 2 installs to the left of Drive 1.
u
For a non-RAID system, one disk drive, with pre-installed operating system and system
software, is standard. This drive is called the boot drive. It is labeled with specific
adapter, channel, and identification number, as follows:
4 GB 0
ADP CH
The boot drive Drive 0 installs in the rightmost slot of the disk drive section.
0 0
Drive 0
ID
0 1
Drive 1
ID
0 2
Drive 2
ID
0 0
Drive 0
ID
13
