Observe the following safety precautions when installing the InterServe 80 SL into a rack or
when using the rack-mounted InterServe 80 SL:
u
Extend only one slide rail set at a time. Push an extended slide rail set back into the rack
before extending another.
WARNING Extending more than one slide rail set could cause the rack to fall forward, causing
damage to the equipment and injuring anyone in front of the rack.
u
Do not push on or lean against the rack. Always engage the stabilizers. The adjustable
feet should be lowered securely against the floor.
u
If the rack contains an AC distribution box or an uninterruptible power supply (UPS), do
not connect the power cord to the wall outlet until instructed to do so in the system
documentation.
u
Set up the InterServe 80 SL completely before you start the system.
After setup is complete, refer to Chapters 2 through 7 for startup and configuration
instructions.

Placing the System Components

When placing InterServe 80 SL components, keep these guidelines in mind:
u
Move and place the monitor and the base unit carefully.
u
Place the base unit in a well-ventilated location where air can circulate freely around it.
u
Do not expose the system to high levels of dust, smoke, or moisture.
u
Maintain the following operating environment.
Temperature range: 50 F to 77 F (10 C to 25 C). Optimum: 70 F (21 C)
Humidity range: 20 % to 80 % non-condensing. Optimum: 50 %
WARNING Once you install equipment into the rack, do not move the rack. If you must move the
rack, first remove all equipment, move the rack to its new location, and then reinstall
the equipment.
CAUTION Do not move the system without first shutting down the system and turning off power, or
damage to internal components may result.
