To set the CPU Speed:
1. If you have not done so already, power down your system and remove the cover.
2. Set the jumper on W12 as follows:
Jumper W12 Setting
Open
Closed
3. Replace the cover, and start the system. BIOS Setup will start automatically.
4. When jumper W12 is closed, the CPU speed displays as the first setting on the Main
screen. Highlight the CPU Speed option and press
increase or decrease the speed, or use the arrow keys to select from the menu.
5. When you have selected the correct speed, you may configure other BIOS settings or
press
F
6. After the BIOS settings are saved, power down the system and remove the jumper from
W12 (store the jumper by placing it on one pin only). The CPU speed setting will no
longer display in the Main screen of BIOS Setup.
NOTE No speed configuration is required when adding a second processor with the same speed as
the original processor. If you forget to remove jumper W12 after you save the CPU speed and
exit, the selection process repeats.

Updating the System BIOS

The system's BIOS can be reprogrammed using a BIOS file. You can update the BIOS by
following the steps below:
1. After loading the appropriate BIOS file from Intergraph's online services, extract it to a
bootable MS-DOS 6.x diskette.
2. Reboot your system with the MS-DOS 6.x diskette in the system's floppy disk drive. To
make sure a clean MS-DOS environment is loaded, press the
Starting MS-DOS is displayed. After the system has restarted, the cursor will display
at the A:> prompt.
3. Now you can run the
README
4. After the update process has completed and the system reboots, verify that the new BIOS
version appears onscreen. If you have problems during this process, or if you have
questions about the procedure, contact Intergraph Computer Systems Customer Support
for help. See the Preface for more information.
Function
Normal (default)
Invoke BIOS Setup to change CPU Speed
10 to save the CPU Speed setting and exit BIOS Setup.
FLASHUTIL
. file included with the BIOS update for detailed instructions.
TXT
ENTER
utility from the bootable diskette. Refer to the
. Use the plus or minus keys to
5 key while the message
F
