In addition to the above shutdown options, the Automatic Shutdown Utility provides the
following features:
u
Force All Processes to terminate: Terminates all programs if checked. If this option is
not checked, the system displays an End Task dialog for each process that may still be
running.
u
Time Remaining: Configures the amount of time before the selected shutdown option
occurs. When the Shutdown utility is started, this timer begins counting down. Press
Enter or click the Stop Shutdown button to stop the countdown timer.
u
Apply button: Apply your selected changes without closing the Shutdown dialog.
u
Cancel: Close the shutdown dialog without saving changes you made.
u
Countdown timer: Stop or start the countdown timer.
NOTE If you select an option while the countdown timer is running, the timer stops automatically.

Drive Status LEDs

The Light-Emitting Diodes (LEDs) on the front of the disk drive section help you determine
disk drive status at a glance. There are two LEDs for each disk drive, making a total of eight
drive status LEDs. The eight drive status LEDs, which display through the window of the disk
drive door, indicate the activity or status for each of the installed drives.
For SCSI disk drives, only the left drive status LED of each drive status LED pair lights. The
left LED for each disk drive flashes to show disk activity.
RAID systems are equipped with a SCSI Activity Fault-Tolerant Enclosure (SAF-TE) card
which monitors the status of the RAID disk drives. The SAF-TE card provides an interface
between the SCSI backplane and the RAID controller, and causes the right drive status LED
of each LED pair to flash according to the drive status. The right drive status LED lights
differently depending on the RAID drive status, as shown in the following table:
Right LED Activity
Off
Steady On
Steady Blink (approx. 1 per second)
Steady Blink (approx. 3 per second)
4 Fast Blinks, Pause (repeats)
2 Fast Blinks, Pause (repeats)
To administer the RAID disk drives and the SAF-TE card, use the Mylex RAID configuration
utility as described in the Mylex RAID controller documentation delivered with the system.
Meaning
No error
Disk drive rebuild stopped, or disk drive is faulty
Disk drive rebuild in progress
Identification of disk drive in progress
Disk drive experienced a predicted fault
Disk drive is a hot spare
