Placing System Components

When placing the system components, keep these guidelines in mind:
u
Place the base unit in a location where air can circulate freely around it. The front and
back panels should each have at least a 3-inch clearance.
u
Do not expose the system to high levels of dust, smoke, or moisture.
u
The location should maintain a temperature range of 10 C/50 F to 26 C/80 F (21
C/70 F optimum), and a humidity range of 20 percent to 80 percent non-condensing (50
percent optimum).

Setting Up

To set up the server:
1. Place the footstands on the bottom of the base unit.
2. Connect the keyboard cable to the keyboard port on the back of the base unit. Refer to
the following figure.
3. Connect the mouse cable to the mouse port on the back of the base unit. Refer to the
following figure.
4. Connect the video cable to the monitor and to the video port on the back of the base unit.
Refer to the following figure.
5. Connect the remaining cables, such as Ethernet (AUI or 10Base-T ports), printer (parallel
port), external SCSI device (SCSI), and modem cables (serial ports), to their ports on the
back of the base unit. Refer to the following figure.
