Removing the Bluetooth Module

1. Turn off the computer, turn it over, and remove the battery
2. The Bluetooth module will be visible at point
3. Remove screws and from the holding plate.
2 3
4. Disconnect the cable and carefully separate the Bluetooth Module from the connector
4
5. Lift the holding plate and Bluetooth Module
6
a.
1
(page 2 -
on the mainboard.
1
(Figure 11c) up and off the computer.
7
b.
2
4
3
5
5) and the component bay cover
(Figure
5
c.
6
7
Removing the Bluetooth Module 2 - 15
Disassembly
Figure 11
Bluetooth Module
(page 2 - 6).
Removal
a. Locate the Bluetooth
11b).
module.
b. Remove the screws from
the holding plate. Dis-
connect the cable and
the connector from the
bluetooth module.
c. Lift the holding plate and
Bluetooth module out.
6. Holding Plate
7. Bluetooth Module
• 2 Screws
