Disassembly

Removing the Keyboard

Figure 12
Keyboard Removal
1. Turn off the computer, and remove the battery
2. Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you
a. Press the four latches to
may need to use a small screwdriver to do this).
release the keyboard.
3. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable
b. Lift the keyboard up and
4. Disconnect the keyboard ribbon cable
disconnect the cable
5. Carefully lift up the keyboard
from the locking collar.
c. Remove the keyboard.
a.
Re-Inserting the
Keyboard
c.
When re-inserting the
keyboard firstly align the
five keyboard tabs at the
Figure 12
bottom ( d) at
the bottom of the key-
board with the slots in the
case.
7. Keyboard
2 - 16 Removing the Keyboard
from the locking collar socket
5
(Figure 12c) off the computer.
7
1 2
3
7
(page 2 - 5).
.
6
b.
4
5
d.
Keyboard Tabs
(Figure 12b).
5
