Removing the Bluetooth Module

1. Turn off the computer, and turn it over and remove the battery
2. Locate the RAM bay cover and remove screws
3. Remove the RAM bay cover
a.
& .
1 2
.
3
b.
2
1
(page 2 - 5).
Removing the Bluetooth Module 2 - 15
Disassembly
Figure 11
Bluetooth Module
Removal
a. Remove the screws.
b. Remove the cover.
3
3. RAM Bay Cover
• 2 Screws
