Removing the Bluetooth Module

1. Turn off the computer and remove the battery
2. Remove screws
3. Carefully lift up the Bluetooth module cover
4. Remove screws
a.
Figure 7
Bluetooth Module
Removal
a. Remove the screws.
b. Carefully lift the cover off
the computer.
c. Remove the screws and
disconnect the cables.
d. Remove the Bluetooth
module.
c.
3. Bluetooth Cover
10. Bluetooth Module
• 6 Screws
2 - 14 Removing the Bluetooth Module
& from the Bluetooth module cover
1 2
- and carefully disconnect cables
4 7
2
1
4 5
9
8
7 6
(page 2 - 8).
.
off the computer.
3
,
& then remove the Bluetooth module
8 9
b.
d.
.
10
