- Page 3 Preface Notebook Computer M560A Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
-
Page 5: About This Manual
Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M560A series notebook PC. -
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. -
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 8: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. -
Page 10: Related Documents
Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII... -
Page 11: Table Of Contents
Preface Contents Introduction ..........1-1 Top (M560A) ................. A-3 Bottom (M560A) ................A-4 Overview ..................1-1 LCD (M560A) ................A-5 System Specifications ......... 1-2 DVD Drive (M560A) ..............A-6 External Locator - Top View with LCD Panel Open ......1-5 Combo Drive (M560A) ..............A-7 External Locator - Front (Audio "DJ")&... - Page 12 Preface Azalia Codec & AMP ..............B-23 Pre Amp AP8202 ................. B-24 SIO FWH IR & CIR ..............B-25 H8 ....................B-26 VCORE ..................B-27 +1.05VS, +2.5VS ................. B-28 +1.8V, 0.9, +1.5V ................. B-29 +VDD3, +VDD5, +VDD12 ............B-30 CHARGER, DC IN ..............B-31 BUTTON BOARD ...............
-
Page 13: Introduction
Introduction 1: Introduction Overview This manual covers the information you need to service or upgrade the M560A series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g. -
Page 14: System Specifications
Introduction System Specifications Feature Specification µ Processor Intel Celeron® M Processor 0.09) 0.09 Micron Process Technology (478-pin) Micro-FCPGA Package 1MB On-die L2 Cache & 400MHz FSB Models 350/ 350J/ 360/ 360J/ 370/ 380/ 390 1.3/ 1.3/ 1.4/ 1.4/ 1.5/ 1.6/ 1.7 GHz Core Logic Intel 915PM + ICH6-M Memory... - Page 15 Introduction Feature Specification Audio 7.1 Channel High Definition Audio Chipset (AZALIA) with UAA (Universal Audio Architecture) EAX™ 1.0 & 2.0 Compatible Direct Sound 3D™ Compatible A3D™ Compatible 16/ 20/ 24-bit S/PDIF-Out Supporting 44.1KHz/ 48KHz/ 96KHz Sample Rate 2 * Built-In Hi-Fi Speakers Built-In Standalone Audio "DJ"...
- Page 16 Introduction Feature Specification Power Supports ACPI 2.0 Supports Hibernate Mode Management Supports Standby Power Full Range AC/DC Adapter 20V, 4.5A (90 Watts), 100~240V, 47~63Hz 8 Cell Smart Lithium-Ion Battery Pack, 4.4AH (for ATI X700 + ATI X800 + NVIDIA 7800 GTX) Optional Battery - 6 Cell Smart Lithium-Ion Battery Pack, 3.8AH (for ATI X700 + ATI X800) Environmental Temperature...
-
Page 17: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View Optional Built-In PC Camera Ap-Key Buttons Power Button Keyboard TouchPad and Buttons Audio "DJ" Controls Built-In Microphone Audio "DJ" LED Display Panel (Including LED Indicators) Audio "DJ" & Power Button Make sure that the Au- dio "DJ"... -
Page 18: External Locator - Front (Audio "Dj")& Rear Views
Introduction External Locator - Front (Audio "DJ") & Rear Views Figure 2 Front Views Audio "DJ" Power Button Volume Down Volume Up Repeat LED Display Previous Track Next Track Play/Pause Stop (Press Twice To Eject The CD/DVD) 10. Repeat Mode Indicator 11. -
Page 19: External Locator - Left & Right Side View
Introduction External Locator - Left & Right Side View Figure 4 Right Side View Headphone-Out M560A Jack Microphone-In Jack 4-in-1 Card Reader PC Card Slot Mini-IEEE 1394a Port 2 * USB 2.0 Ports Security Lock Slot Speaker Figure 5 Left Side View 1. -
Page 20: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View M560A Vent/Fan Intake/ Outlet Video Card Cover Battery Optical Device Release Latches HDD / RAM Bay Cover Infrared & Consumer Infrared Transceiver M540V Overheating To prevent your com- puter from overheating make sure nothing... -
Page 21: M560A Mainboard Overview - Top (Key Parts)
Introduction M560A Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. CPU Socket (no CPU installed) 2. VGA Sockets 3. Northbridge-Intel 915PM 4. Memory Slots DDR2 So-DIMM 5. Mini-PCI Socket (Wireless Lan Module) 6. Audion Amp. 7. -
Page 22: M560A Mainboard Overview - Bottom (Key Parts)
Introduction M560A Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. PC Card Assembly 2. Southbridge-Intel ICH6-M 3. Bluebird VLT 4. H85/211 5. Ultra Media 6. Flash BIOS ROM 7. RTL8110 8. GS5019P 1 - 10 M560A Mainboard Overview - Bottom (Key Parts) -
Page 23: M560A Mainboard Overview - Top (Connectors)
Introduction M560A Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. S/PDIF-Out Jack 2. Line-In Jack 3. USB Port 4. DVI-Port 5. TV -In Jack 6. RJ-11 Jack 7. RJ-45 Jack 8. S-Video Jack 9. DC-In Jack 10. Battery Connectors 11. -
Page 24: M560A Mainboard Overview - Bottom (Connectors)
Introduction M560A Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Keyboard Connector 2. Speaker-1 Connector 3. Com Connector 4. Inventer Board Connector 5. CCD Connector 6. Modem Module Connector 7. Buttom Connector 8. ADJ Connector 9. Touch Pad Connector 1 - 12 M560A Mainboard Overview - Bottom (Connectors) -
Page 25: Disassembly
Disassembly 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M560A series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. Procedures such as upgrading/replacing the RAM, CD device and hard disk are included in the User’s Manual but are repeated here for your convenience. -
Page 26: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 27: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 28: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Optical Device: 1. Remove the battery page 2 - 5 1. -
Page 29: Removing The Battery
Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow, and hold it in place. a. Slide the latch and hold 3. Lift the battery out at point , in the direction of the arrow in place. -
Page 30: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives Removal with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk. -
Page 31: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 3 RAM Module The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDRII (DDR2) 533 MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are 256MB, 512MB and 1024MB DDRII Modules. -
Page 32: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 4 Wireless LAN 1. Turn off the computer, and turn it over remove the battery (page 2 - Module Removal 2. Locate the bay cover and remove screws ( 3. Remove the bay cover a. -
Page 33: Removing The Bluetooth Module
Disassembly Removing the Bluetooth Module Figure 5 Bluetooth Module 1. Turn off the computer, and turn it over remove the battery (page 2 - Removal 2. Locate the bay cover , and remove screws 3. Remove the bay cover a. Remove the screws and 4. -
Page 34: Removing The Tv Tuner Card
Disassembly Removing the TV Tuner Card Figure 6 TV Tuner Card 1. Turn off the computer, and turn it over remove the battery (page 2 - Removal 2. Locate the bay cover , and remove screws 3. Remove the bay cover a. -
Page 35: Removing The Optical (Cd/Dvd) Device
Disassembly Removing the Optical (CD/DVD) Device Figure 7 Optical Device 1. Turn off the computer, and turn it over and remove the battery. Removal 2. Slide the latch in the direction of the arrow, and hold it in place. 3. Eject the optical device by carefully sliding the latch in the direction of the arrow. -
Page 36: Removing The Processor
Disassembly Removing the Processor Figure 8 Processor Removal 1. Turn off the computer, and turn it over and remove the battery (page 2 - 2. Locate the CPU bay cover , and remove screws a. Remove the screws. 3. Carefully lift up the CPU cover off the computer. - Page 37 Disassembly 6. Turn the release latch towards the unlock symbol , to release the CPU (Figure 9a). Figure 9 7. Carefully (it may be hot) lift the CPU up out of the socket (Figure 9b). Processor Removal 8. Reverse the process to install a new CPU. (cont’d) 9.
-
Page 38: Removing The Vga Card
Disassembly Removing the VGA Card Figure 10 VGA Card Removal 1. Turn off the computer, and turn it over and remove the battery (page 2 - 2. Locate the bay cover , and remove screws a. Remove the screws. 3. Remove the bay cover b. -
Page 39: Removing The Keyboard
Disassembly Removing the Keyboard Figure 11 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you a. - Page 40 Disassembly 2 - 16...
-
Page 41: Part Lists
Part Lists Appendix A:Part Lists This appendix breaks down the M560Aseries notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 42: Part List Illustration Location
Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part M560A Location page A - 3 Top - (M560A) page A - 4 Bottom - (M560A) page A - 5 LCD - (M560A) page A - 6... -
Page 43: Top (M560A
Part Lists Top (M560A) Figure A - 1 Top (M560A) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 漢保 無鉛 無鉛 Top (M560A) A - 3... -
Page 44: Bottom (M560A
Part Lists Bottom (M560A) 無鉛 無鉛 無鉛 無鉛 EMI GASKET FOR 雙層USB 長13MMX寬 7MMX高4MM 無鉛 無鉛 無鉛 無鉛 無鉛 Figure A - 2 無鉛 Bottom (M560A) 無鉛 無鉛 無鉛 無鉛 華力 無鉛 無鉛 (銅釘套管) 無鉛 CPU COVER MODULE 不噴漆 無鉛 無鉛... -
Page 45: Lcd (M560A
Part Lists LCD (M560A) Figure A - 3 LCD (M560A) 無鉛 無鉛 無鉛 華力 華力 華力 無鉛 無鉛 無鉛 中性 無鉛 無鉛 LCD (M560A) A - 5... -
Page 46: Dvd Drive (M560A
Part Lists DVD Drive (M560A) Figure A - 4 DVD Drive (M560A) A - 6 DVD Drive (M560A) -
Page 47: Combo Drive (M560A
Part Lists Combo Drive (M560A) Figure A - 5 Combo Drive (M560A) Combo Drive (M560A) A - 7... -
Page 48: Dvd-Rw Drive (M560A
Part Lists DVD-RW Drive (M560A) Figure A - 6 DVD-RW Drive (M560A) A - 8 DVD-RW Drive (M560A) -
Page 49: Hdd (M560A
Part Lists HDD (M560A) Figure A - 7 HDD (M560A) HDD (M560A) A - 9... -
Page 50: Second Hdd (M560A
Part Lists Second HDD (M560A) Figure A - 8 Second HDD (M560A) A - 10 Second HDD (M560A) -
Page 51: Schematic Diagrams
Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M560A notebook’s PCB’s. The following table indicates where to find the ap- propriate schematic diagram. Table B - 1 Diagram - Page Diagram - Page Diagram - Page Schematic System Block Diagram - Page B - 2 CARD BUS &... -
Page 52: System Block Diagram
Schematic Diagrams System Block Diagram BOTTON BOARD 1.+VCORE 1.POWER BOTTON M560A BLOCK DIAGRAM SHEET 25 2.INSTANT KEY X 3 1.+1.05VS,+2.5VS 3.LID SWITCH SHEET 26 71-M56AF-D01 SHEET 31 CARD READER BOARD 1.+1.8V,+1.5V,+0.9V SHEET 27 1.CARD READER 71-M56AV-D01 SHEET 32 1.CHARGER,DC IN BOARD M560A Dothan CPU CK-410M... -
Page 53: Clock Generator
Schematic Diagrams CLOCK GENERATOR +3VS HCB1608K-121T25 VDD48 +3VS +3VS HCB1608K-121T25 10UF/6.3V 0.1UF_X7R 0.1UF_X7R C408 C406 0.1UF_X7R 10UF/6.3V HCB3216K-800T30 CPUCLK R284 49.9_1%/0402 CPUCLK# R283 49.9_1%/0402 MCHCLK 49.9_1%/0402 MCHCLK# 49.9_1%/0402 Sheet 2 of 40 ITPCLK R282 49.9_1%/0402 ITPCLK# R281 49.9_1%/0402 4P2RX33 SRCCLK_VGA 49.9_1%/0402 C412 CPUCLK0... -
Page 54: Cpu-1
Schematic Diagrams CPU-1 HD[0:63] HD[0:63] U29B HREQ#[4:0] U29A HD32 D32# AA24 HD33 K_A20M# 12 A20M# D33# HREQ#0 HD34 REQ0# FERR# FERR# D34# HREQ#1 HD35 IGNNE# REQ1# IGNNE# D35# HREQ#2 HD36 REQ2# STPCLK# STPCLK# 12 D36# HREQ#3 HD37 REQ3# LINT0 INTR D37# HREQ#4 HD38... -
Page 55: Cpu-2
Schematic Diagrams CPU-2 U29D VSS0 VSS96 VSS1 VSS97 VSS2 VSS98 VSS3 VSS99 V_CORE VSS4 VSS100 VSS5 VSS101 VSS6 VSS102 VSS7 VSS103 1.708 1.196 VSS8 VSS104 U29C VSS9 VSS105 1.692 1.180 VSS10 VSS106 AD18 VCC0 VCC59 VSS11 VSS107 1.676 1.164 VCC1 VCC60 VSS12 VSS108... -
Page 56: Alviso-1
Schematic Diagrams Alviso-1 U31A +3VS +1.05VS U31E *HCB1608K-121T25 HD[0:63] HA[3:31] C671 C672 +3VS HD0# HA3# VCC0 VCCA_TVDACA0 *HCB1608K-121T25 HD1# HA4# C673 C674 *0.1UF VCC1 VCCA_TVDACA1 HD2# HA5# C100 C107 VCC2 VCCA_TVDACB0 HD3# HA6# *0.1UF VCC3 VCCA_TVDACB1 HD4# HA7# 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF... -
Page 57: Alviso-2
Schematic Diagrams Alviso-2 +1.05VS +1.5VS U31G 4.7K/0402 R297 U31B SDVOCTRL_DATA EXP_COMPI 24.9_1% DMI_TXN[0..3] SDVOCTRL_CLK EXP_ICOMPO DMI_TXN0 AA31 AB29 SRCCLK_MCH# PCIE_RXN[0..15] 10 DMIRXN0 CFG0 GCLKN DMI_TXN1 AB35 AC29 PCIE_RXN0 DMIRXN1 CFG1 CPU_BSEL1 2,3 SRCCLK_MCH GCLKP EXP_RXN0 DMI_TXN2 AC31 PCIE_RXN1 DMIRXN2 CFG2 CPU_BSEL0 2,3 EXP_RXN1 DMI_TXN3... -
Page 58: Alviso-3
Schematic Diagrams Alviso-3 U31H AB26 +1.05VS VCC_NCTF0 VSS_NCTF0 AA26 VCC_NCTF1 VSS_NCTF1 VCC_NCTF2 VSS_NCTF2 AB25 VCC_NCTF3 VSS_NCTF3 AA25 M_A_DQ[0..63] M_B_DQ[0..63] VCC_NCTF4 VSS_NCTF4 U31C U31D VCC_NCTF5 VSS_NCTF5 AB24 VCC_NCTF6 VSS_NCTF6 M_A_DQ0 AG35 AK15 M_A_BS#0 M_B_DQ0 AE31 AA24 M_A_BS#0 8 SADQ0 SA_BS0# SBDQ0 VCC_NCTF7 VSS_NCTF7 M_A_DQ1... -
Page 59: Dimm A
Schematic Diagrams DIMM A +VTT_MEM RESISTORS +0.9VS 16-56034-45A M_A_BS#1 RN29 C184 0.1UF_X7R M_A_A0 4P2RX56_04 M_A_A4 RN27 C186 0.1UF_X7R JDIMM2A M_A_A2 4P2RX56_04 M_A_A[13:0] M_A_DQ[63:0] 7 M_A_A0 M_A_DQ0 M_A_A1 M_A_DQ1 M_A_A1 RN28 C188 0.1UF_X7R M_A_A2 M_A_DQ2 M_A_A3 4P2RX56_04 M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A7 RN25 C190... -
Page 60: Dimm B
Schematic Diagrams DIMM B +VTT_MEM RESISTORS +0.9VS 16-56034-45A M_B_RAS# RN15 C172 0.1UF_X7R M_B_BS#1 JDIMM1A 4P2RX56_04 M_B_A[13:0] M_B_DQ[63:0] 7 M_B_A0 M_B_DQ0 M_B_A1 M_B_DQ1 M_B_WE# RN20 C170 0.1UF_X7R M_B_A2 M_B_DQ2 M_B_A5 4P2RX56_04 M_B_A3 M_B_DQ3 M_B_A4 M_B_DQ4 M_CS#2 RN16 C164 0.1UF_X7R M_B_A5 M_B_DQ5 M_B_A3 4P2RX56_04 M_B_A6... -
Page 61: Vga Card Connector
Schematic Diagrams VGA CARD CONNECTOR DVI_HPD C318 0.1UF CON2 DVI_5VS JDVI1 TXM0 TXCM +5VS TXP0 TXCP CON1 CASE 1SS355 TXM1 DAC1_HSYNC TXM2 TMDS DATA 2- TXP1 DAC1_VSYNC TXP2 TMDS DATA 2+ C395 C394 0.1UF/50V 100K R232 RB751V TMDS 2/4 Shield TXM2 DAC1_R 0.1UF/50V... -
Page 62: Ich6M-1
Schematic Diagrams ICH6M-1 U13C R338 U13B HSIN[0] PCIE_RN0 19 15,17,18 AD[0:31] (+3V) PREQ#0 HSIP[0] PCIE_RP0 19 AD_0 REQ[0]# PREQ#0 AF17 C510 0.1UF PGNT#0 +3VS PCIE_TN0 19 PGNT#0 SATA[0]GP/GPIO[26] HSON[0] AD_1 GNT[0]# AE18 C511 0.1UF PREQ#1 SATA[1]GP/GPIO[29] HSOP[0] PCIE_TP0 19 AD_2 REQ[1]# PREQ#1 AF18... -
Page 63: Ich6M-2
Schematic Diagrams ICH6M-2 U13A CLK_32X1 RTCX1 LAD_0/FB0 LPC_AD0 24,25 CLK_32X2 CDD[0..15] RTCX2 LAD_1/FB1 LPC_AD1 24,25 CDD[0..15] R339 LAD_2/FB2 LPC_AD2 24,25 RTC_RST# +VCCRTC LPC_AD3 24,25 RTCRST# LAD_3/FB3 JHDD1 SM_INTRUDER# R318 ▲ LPC_DRQ# 24 INTRUDER# LDRQ_0# C451 R346 CRESETN +3VS INTVRMEN LDRQ_1#/GPI41 CRESETN 21 *8.2K 1UF/0603... -
Page 64: Ich6M-3
Schematic Diagrams ICH6M-3 +1.5VS +1.5VS U13E U13D AA22 VCC1_5_1 VCC1_5_98 VSS1 VSS87 AA23 VCC1_5_2 VCC1_5_97 VSS2 VSS88 C114 AA24 C116 VCC1_5_3 VCC1_5_96 VSS3 VSS89 C496 C502 C500 AA25 C497 C505 C488 C506 C489 VCC1_5_4 VCC1_5_95 VSS4 VSS90 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF... -
Page 65: Usb & Ccd Conn
Schematic Diagrams USB & CCD CONN USBVCC0 CCD_+5V TRACE WIDTH > 50mil HCB2012K-500T40 TRACE WIDTH > 50mil R230 C418 USBVCC0 0.1UF 10UF/10V 150K C304 C302 0.1UF JCCD1 R229 100UF/16V JUSB1 MCM2012B181F 270K VOUT USBVCC7 USBN5 OC#0 VCC0 C117 GND1 USBP5 10UF/10V USBN0 C305... -
Page 66: Card Bus & 1394-1
Schematic Diagrams CARD BUS & 1394-1 CardBus U20-2 VCCCA U20-1 U20-3 VCCA VCCP VCCA VCCB R149 JPCM56 VCCP VCCB CAD31 JPCM57 11,17,18 AD[0..31] A_CAD31/A_D10 AD31 CAD30 VPPA AD31 A_CAD30/A_D9 B_CAD31/B_D10 AD30 CAD29 CAD0 VPPA AD30 A_CAD29/A_D1 B_CAD30/B_D9 D3 - CAD0 AD29 CAD28 CAD1... -
Page 67: Card Bus &1394-2
Schematic Diagrams CARD BUS &1394-2 Initialization EEPROM For EEPROM, resistors should be placed on the SCL and SDA terminals Initialization EEPROM U20-8 C588 PWR_CTRL 0.1UF For EEPROM, resistors should be placed on the SCL and SDA MC_PWR_CTRL_0 SD_CD# JCREADER1 MC_PWR_CTRL_1 SD_CD MS_CD# terminals... -
Page 68: Minipci
Schematic Diagrams MINIPCI PIRQ#G R173 PIRQ#E R176 PIRQ#H R174 M2_IRQ PIRQ#F R177 M1_IRQ CIR_RX R141 +3VS RB751V +3VS +3VS +3VS +3VS JMINIPCI1 JMINIPCI2 +5VS C261 C218 C213 C214 C223 C267 C222 C219 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF WL_PWR_EN C268 0.1UF... -
Page 69: Realtek Giga Lan
Schematic Diagrams REALTEK GIGA LAN LAN_DVDD 40 mil RLANVDD3 BK2125HS121 100 mil RLANVCC1.3 C687 C688 C689 C690 C691 C692 C693 BK2125HS121 10U/6.3V 0.1U C694 C695 10U/6.3V 0.1U 0.1U 0.1U 0.1U 0.1U 10U/6.3V LAN_AVDDL 40 mil BK2125HS121 RLANVCC2.5 C696 C697 C698 C699 0.1U 0.1U... -
Page 70: Pcie Giga Lan
Schematic Diagrams PCIE GIGA LAN LAN_VDD33 R255 R254 LANVCC2.5 *4.7K *4.7K SMBCLK JLAN1 2,8,9,11,18,21 SMBCLK JMODEM1 HK2125 R10J-T SMBDATA 2,8,9,11,18,21 SMBDATA ▲ LAN_VDD33 R250 *HCB-2012K-121T30 RING HK2125 R10J-T ▲ R252 C355 85204-2 *0.1UF *GST5009 MDI3- TD4- MX4- MDI3+ TD4+ MX4+ V_DAC C358 TCT4... -
Page 71: Ac97
Schematic Diagrams AC97 R434 +VDD12 +12V R435 2N7002 ALC202 ALC655 2N7002 C615 AC97_VDD SPDIF/SURRB-L SPDIF/SURRB-L +3VCDROM R465 C615 *1UF C575 C610 C613 Sheet 20 of 40 0.1UF 0.1UF Vaux DCVOL C579 1000PF VRDA AC97 AVDD VRAD AC97_VDD ALC202 AVDD AFILT2 C578 1000PF AGND... -
Page 72: Audio-Dj
Schematic Diagrams AUDIO-DJ +3VCDROM +5VCDROM +3VCDROM VCC5 VCC5 C_ACRST# R369 J-ADJ1 F_DD6 R360 BlueBirdVL F_DD7 R358 C519 C515 SD_DAT2 R355 BB_WP PLAY_PAUSE C516 C513 C514 C517 0.1UF 0.1UF R601 PLAY_PAUSE 25 STOP_EJECT / VL+ STOP_EJECT 25 port1[0]/F_DD0 PDLED# 0.1UF 0.1UF 0.1UF 0.1UF BBLED_STB... -
Page 73: Azalia Codec & Amp
Schematic Diagrams Azalia Codec & AMP 10UF/6.3V +3VS +5VS BK2125HS121(0805) BK2125HS121(0805) C605 C606 C603 JINTMIC1 C622 C618 C602 0.1UF 10UF/6.3V 10UF/6.3V 0.1UF 0.1UF C512 CON2_MIC 330PF LFEOUT 14 INTMICO 14 C604 GPIO0/XTLI VREF GPIO1 10UF/6.3V HCB1608K-121T25 GPIO1/XTLO MICO 14 C620 *10PF V_REFOUT C633... -
Page 74: Pre Amp Ap8202
Schematic Diagrams Pre Amp AP8202 R591 C283 10UF/6.3V AC97_OUT_R C284 10UF/6.3V FRONT-R R592 C287 10UF/6.3V AC97_OUT_L C286 10UF/6.3V FRONT-L R210 R207 6.8K R493 R494 WOWO_VDD C282 C281 Sheet 23 of 40 R216 2.2K C651 0.1UF 0.1UF 10UF/6.3V 5.1K R217 2.2K C650 0.1UF Pre Amp AP8202... -
Page 75: Sio Fwh Ir & Cir
Schematic Diagrams SIO FWH IR & CIR +3VS C232 C231 C270 C224 10UF/6.3V 0.1UF 0.1UF 0.1UF +3VS C225 C725 0.1UF COM PORT C229 12,25 LPC_AD0 LAD0 JCOM1 12,25 LPC_AD1 LAD1 0.1UF 12,25 LPC_AD2 LAD2 DCDO# 12,25 LPC_AD3 LAD3 C227 C228 RXDO PCLKSIO LCLK... - Page 76 Schematic Diagrams H8_BATTEMP_A C545 +3VH8 +3VH8 +3VH8 +3VH8 +VDD5 H8_BATVOLT_A C544 HCB2012K-121T30 RP10 KB-SI0 WL_PWR_EN KB-SI1 KB-SI7 BT_EN# KB-SI3 +3VH8 H8_BATTEMP_B C543 PM_THRM# KB-SI6 H8_VRON KB-SI2 KB-SI5 H8_BATVOLT_B C542 SRS_CNTL# CCD_DET# KB-SI4 LID_RSUM# C207 C548 C593 C209 C210 C546 C547 C177 H8_GA20 H8_CURSEN...
-
Page 77: Vcore
Schematic Diagrams VCORE +3VS OPEN_10mil PR34 PM_PSI# H_VID5 PR134 +5VS +VDD5 H_VID4 PR35 PR33 H_VID3 PR36 H_VID2 PR135 H_VID1 PR37 OPEN_10mil H_VID0 PR136 +3VS +VDD3 H_VID[5:0] +5VS PR133 PR128 PR138 49.9K 1% 22K 1% 5.36K 1% PC138 PC38 PC26 100pF PR121 10uF_25V 10uF_25V... -
Page 78: Vs, +2.5Vs
Schematic Diagrams +1.05VS, +2.5VS PR25 +VDD5 VIN1 PC91 PC90 PC89 PC88 PR24 10uF_25V 10uF_25V 10uF_25V 10uF_25V PD17 PR27 PR68 270K RB751V PQ22 AO4408 EN/PSV 1.05V PC87 0.1uF +1.05VS PQ33 2N7002 PC85 PR69 2 1.5UH PR23 100K +VDD5 VOUT 0.1UF 15.8K PR22 PC21 8mm(8A) -
Page 79: V, 0.9, +1.5V
Schematic Diagrams +1.8V, 0.9, +1.5V +0.9VS PC79 PC80 0.1U 4.7uF_0805 PQ20A PR65 0_1206 +1.8V VBST VLDOIN PC78 AO4900 4.7uF_0805 DRVH PR66 PC65 PC62 PC64 PC69 VTTGND PR221 0 0.1UF 0.1UF 0.1UF 0.1UF DRVL VTTSNS +0.9VS PJ15 PC204 *220U/4V_B 1.0UH PR222 OPEN_3A +1.8V PGND... -
Page 80: Vdd3, +Vdd5, +Vdd12
Schematic Diagrams +VDD3, +VDD5, +VDD12 +VDD12 PJ14 OPEN_10mil 0.1A PQ62 PQ63 2SC4672 0.1A DTA114EUA PJ12 +12V VIN1 PR207 OPEN 11.5K_1% PR205 1K PR192 PC189 PD12 PQ60 PC217 PC82 10U/25V_1206 PC161 11FS2 PR201 DTC114EUA 10U_0805 10U/25V SYSTEMON 25,28,30 PC188 PC184 *5.6U/25V_B PQ65 1.2K_1%_0805 PC173... -
Page 81: Charger, Dc In
Schematic Diagrams CHARGER, DC IN BAT_A VA++ PQ32 AO4433 PQ36 PD19 JAC1 20m_2512 15uH PR28 25m_2512 AO4433 0.1UF/50V(0805) 0.1UF/50V(0805) *0(1206) VA++ 10UF/25V_1206 SM340B PC128 PC127 PC111 PC112 PD16 PC125 PC126 PR113 ACIN_CON PC114 PC113 CHARGE 4S(16.8) PIN GND1~5 =GND 0.1UF/50V(0805) PC207 SM340A 0.1U(0805) -
Page 82: Button Board
Schematic Diagrams BUTTON BOARD B+5V B+5V *680 B+3VH8 BJLED1 BDGND BPWRON_LED *2.7K POWER POWER BPWRBTN# BLID_RSUM# BUTTON *LED_1206 BUTTON LED_1206 BWEB#0 BLID_RSUM# BWEB#1 BWEB#2 M570A M560A B+5V 0.01UF TLE_4917 B+3VH8 BCON10 0.1UF 0.1UF BDGND SWTICH BDGND BPWRON_LED BPWRON_LED M560A BDGND Sheet 31 of 40 *DTC114EUA DTC114EUA... -
Page 83: Card Reader Board
Schematic Diagrams CARD READER BOARD CJCREADER2 CJCREADER2 CMS_CLK/SD_CLK CMS_CLK/SD_CLK CMS_BS/SD_CMD CMS_BS/SD_CMD CMS_DATA3/SD_DAT3 CMS_DATA3/SD_DAT3 新增排阻 新增排阻 隔離干擾 隔離干擾 CMS_DATA2/SD_DAT2 CMS_DATA2/SD_DAT2 CMS_DATA1/SD_DAT1 CMS_DATA1/SD_DAT1 CMS_SDIO/SD_DAT0 CMS_SDIO/SD_DAT0 CCON6 CCON6 CJREADER1 CJREADER1 CSD_WP CSD_WP SD-WP-SW SD-WP-SW CMS_DATA1/SD_DAT1 CMS_DATA1/SD_DAT1 CJCREADER56 CJCREADER56 SD-DATA1 SD-DATA1 CMS_SDIO/SD_DAT0 CMS_SDIO/SD_DAT0 SD-DATA0 SD-DATA0 CMS_SD3_3V CMS_SD3_3V... -
Page 84: Usb Board M560A
Schematic Diagrams USB BOARD M560A UGND 0.1UF UJUSB1 UUSBOVCC1 UUSBN1 DATA_L GND4 GND3 UUSBP1 DATA_H MCM2012B181F UJEXT1 UUSBOVCC1 UUSBN1 UUSBP1 UGND UUSBOVCC6 UUSBN6 UGND UUSBP6 Sheet 33 of 40 U1394A0P U1394A0N USB BOARD U1394B0P UGND U1394B0N M560A USPKOUTR 0.1UF UBTL# UJUSB2 USPKOUTL UUSBOVCC6... -
Page 85: Usb Board M570A
Schematic Diagrams USB BOARD M570A VJEXT1 VUSBOVCC1 0.1UF VUSBN1 VGND VUSBP1 VJUSB1 VUSBOVCC6 VUSBOVCC1 VUSBN6 VUSBP6 VUSBN1 DATA_L GND4 GND3 V1394A0P VUSBP1 DATA_H V1394A0N MCM2012B181F V1394B0P V1394B0N VSPKOUTR VBTL# VSPKOUTL VGND VLFEOUT VINTMICO VGND VMICO VCON20 0.1UF VGND VGND Sheet 34 of 40 VJUSB2 VUSBOVCC6 USB BOARD... -
Page 86: Com Port Board
Schematic Diagrams COM PORT BOARD EJCOM1 ELP2 EJCOM2 8P4LXBLA3216A221SG4 EDCD# ERING# ERXD EDTR# ETXD ECTS# EDTR# ETXD EDSR# ERTS# ERTS# ERXD ECTS# EDSR# ERING# EDCD# 8P4LXBLA3216A221SG4 ECOM1_DB9 ECON9 ELP1 ECP1 ECP2 Sheet 35 of 40 8P4CX180PF EDGND 8P4CX180PF COM PORT BOARD EDGND EDGND MTH276D111... -
Page 87: Audio Dj Board
Schematic Diagrams AUDIO DJ BOARD AJ-ADJ1 ▲ APLAY_PAUSE AVCC_LED *100U ASTOP_EJECT APDLED# A+5VCDROM AGR1 AVOLUM_DOWN AVOLUM_UP AGR2 AGR3 ACDPWRBTN# 0.1UF A_AH8LED_CLK1 AGR4 AGR5 A_AH8LED_DATA ADGND A_AH8LED_CLK2 AR47 AGR6 ABBLED_DATA AGR1 ABBLED_STB AGR7 ABBLED_CLK AGR2 100K 100K ABBLED_CLK AR43 ASG8 ADGND ABBLED_STB AGR3 ABBLED_DATA... -
Page 88: Click Board
Schematic Diagrams CLICK BOARD M560A M570A M560A AYNAPTICS AYNAPTICS ELANTECH ELANTECH GTP_R_56 GJTP1 G+5VS G+5VS G+5VS GJTP2 GTP_DATA GTP_L_56 GTP_CLK GTP_CLK GTP_DATA GTP_CLK GTP_R_57 GTP_R_56 GR11 GR19 GTP_CLK GR10 GR10 GCON1 GTP_SCRRIGHT_57 GR13 GR10 GR12 GR12 GTP_DATA 0.1UF GR11 GTP_SCRUP_57 GR15 GR12 GR14... -
Page 89: Pata Hdd Board
Schematic Diagrams PATA HDD BOARD DJHDD1 DJHDDEXT1 DCRESETN DCRESETN DCDD8 DCDD7 DCDD8 DCDD7 DCDD9 DCDD6 DCDD9 DCDD6 DCDD10 DCDD5 DCDD10 DCDD5 Sheet 38 of 40 DCDD11 DCDD4 DCDD11 DCDD4 DCDD12 DCDD3 DCDD12 DCDD3 DCDD13 DCDD2 DCDD13 DCDD2 PATA HDD BOARD DCDD14 DCDD1 DCDD14... -
Page 90: Sata Hdd Board
Schematic Diagrams SATA HDD BOARD SATA CONN SJHDDEXT1 S+3VS SJSATA1 SCRESETN SCDD8 SCDD7 3900PF SSATATXP0 SCDD9 SCDD6 3900PF SSATATXN0 SCDD10 SCDD5 SCDD11 SCDD4 3900PF SSATARXN0 SCDD12 SCDD3 Sheet 39 of 40 3900PF SSATARXP0 SCDD13 SCDD2 SCDD14 SCDD1 SATA HDD BOARD SCDD15 SCDD0 SCDMARQ... -
Page 91: Second Hdd Board
Schematic Diagrams SECOND HDD BOARD E+5VCDROM EJCD1 EJHDD1 EINT_CD_R EINT_CD_L ECRESETN ECD_GND ECRESETN ECDD8 ECDD7 ECDD8 ECDD7 ECDD9 ECDD6 ECDD9 ECDD10 ECDD5 ECDD10 ECDD6 ECDD11 ECDD4 ECDD11 ECDD5 ECDD12 ECDD3 ECDD12 ECDD4 ECDD13 ECDD2 ECDD13 ECDD3 ECDD14 ECDD1 ECDD14 ECDD2 ECDD15 ECDD0 ECDD15... - Page 92 Schematic Diagrams B - 42...
