Removing the Wireless LAN Module

1. Turn off the computer, turn it over, and remove the battery
2. The wireless LAN module will be visible at point
3. Carefully disconnect the cable
4. The wireless LAN module
5
a.
1
b.
4
2
3
(page 2 -
on the mainboard.
1
, and then remove the screws
2
(Figure 9c) will pop-up, and you can remove it.
c.
5
5) and the component bay cover
- .
3 4
d.
5
Removing the Wireless LAN Module 2 - 13
Disassembly
Figure 9
Wireless LAN
(page 2 - 6).
Module Removal
a. Locate the WLAN.
b. Disconnect the
and remove the
screws.
c. The WLAN module will
pop up.
d. Remove the Wireless
LAN module.
Note: Make sure you
reconnect the antenna
cable to the "Main"
socket (Figure 9b).
5.Wireless LAN Module
cable
2
