Removing the System Memory (RAM)

The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting
DDRII (DDR2) Up to 667 MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are
256MB, 512MB and 1024MB DDRII Modules. The total memory size is automatically detected by the POST routine
once you turn on your computer.
Memory Upgrade Process
1. Turn off the computer, turn it over and remove the battery
2. The RAM module(s) will be visible at point
3. Gently pull the two release latches (
arrows (Figure 5b).
a.
1
4. The RAM module(s) will pop-up
4
5. Pull the latches to release the second module if necessary.
6. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot.
7. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot
as it will go. DO NOT FORCE IT; it should fit without much pressure.
8. Press the module in and down towards the mainboard until the slot levers click into place to secure the module.
9. Replace the bay cover and the screws
10. Restart the computer to allow the BIOS to register the new memory configuration as it starts up.
(page 2 -
on the mainboard.
1
& ) on the sides of the memory socket in the direction indicated by the
2 3
c.
b.
2 3
( Figure 5c ) , and you can then remove it
(see page 2 - 6 ) .
5) and the component bay cover
4
.
Removing the System Memory (RAM) 2 - 9
Disassembly
Figure 5
RAM Module
Removal
a. Locate the memory
socket.
b. Pull the release
latch(es).
(page 2 - 6).
c. Remove the mod-
ule(s).
Contact Warning
Be careful not to touch
the metal pins on the
4
module's connecting
edge. Even the cleanest
hands have oils which
can attract particles, and
degrade the module's
performance.
4. RAM Module
