Disassembly

Removing the VGA Card

Figure 8
VGA Card Removal
1. Turn off the computer, turn it over, and remove the battery
the CPU heat sink
a. Locate the VGA.
2. The VGA Card(s) will be visible at point
b. Remove the screws.
3. Remove screws
c. Lift the VGA card up and
4. Carefully grip the plastic holder and lift the video card
off the sockets.
5. Reverse the process to install the new VGA Card.
6. VGA Card
• 4 Screws
2 - 12 Removing the VGA Card
(page 2 - 10).
- (Figure 8b) .
2 5
a.
1
(page 2 - 5), the component bay cover
on the mainboard.
1
up and off the sockets (
6
b.
c.
(page 2 - 6) and
& ).
7 8
4
2
3
5
6
7
8
