Mainboard Overview - Bottom (Connectors)

Figure 10
Mainboard Bottom
Connectors
1. S/PDIF-Out Jack
2. Line-In Jack
3. USB Port
4. DVI-Out Port
5. TV Antennna Jack
6. RJ-11 Jack
7. RJ-45 Jack
8. 7-Pin S-Video-Out
Jack
9. DC-In Jack
10. Battery Connector
11. Mini-IEEE 1394a
Port
12. 7-in-1 Card Reader
Connector
13. Microphone Jack
14. Headphone Jack
15. Battery Cable
Connector
16. Bluetooth Cable
Connector
17. HDD Connector
18. LCD Cable
Connector
19. CD Connector
20. Debug Connector
1 - 14 Mainboard Overview - Bottom (Connectors)
1
3
3
11
12
16
15
13
14
2 3 4 5 6
17
7 8 9
10
18
19
20
