Introduction

System Specifications

Feature
Processor Types
Core Logic
LCD
Security
Memory
BIOS
1 - 2 System Specifications
Intel® Core™ Duo Processor
(478-pin) Micro-FC-PGA Package
T2300/ T2400/ T2500/ T2600/ T2700
Intel® Core™ Duo Processor
(478-pin) Micro-FC-PGA Package
T5600
Intel® Core™ Duo Processor
(478-pin) Micro-FC-PGA Package
T7200/ T7400/ T7600
Intel® Core™ Solo Processor
(478-pin) Micro-FC-PGA Package
T1300/ T1400
Intel 945GM + ICH7-M DH
Flat Panel TFT (For One of the Following Options)
17" WXGA (1440 * 900) TFT LCD
OR
17" WSXGA+ (1680 * 1050) TFT LCD
OR
17" WUXGA (1920 * 1200) TFT LCD
Security (Kensington® Type) Lock Slot
Two 200 Pin SO-DIMM Sockets Supporting DDRII (DDR2) Up To 667 MHz
128-bit Wide DDRII (DDR2) Data Channel
Memory Expandable up to 2GB (256/ 512/ 1024 MB DDRII Modules)
(Note: Do Not Use Other Module Types)
One 512KB Flash ROM
Specification
65nm (65 Nanometer) Process Technology
2MB On-die L2 Cache & 667MHz FSB
1.66/ 1.83/ 2.0/ 2.16/ 2.33 GHz
65nm (65 Nanometer) Process Technology
2MB On-die L2 Cache & 667MHz FSB
1.83 GHz
65nm (65 Nanometer) Process Technology
4MB On-die L2 Cache & 667MHz FSB
2.0/ 2.16/ 2.33 GHz
65nm (65 Nanometer) Process Technology
2MB On-die L2 Cache & 667MHz FSB
1.66/ 1.83 GHz
BIOS Password
Phoenix BIOS
