External Locator - Rear View

Figure 3
Rear View
1. Vent/Fan Intake/
Outlet
2. S/PDIF-Out Jack
3. Line-In Jack
4. 2 * USB 2.0 Ports
5. DVI-Out Port
6. TV Antenna Jack
(Enabled With TV
Tuner Only)
7. RJ-11 Phone Jack
8. RJ-45 LAN Jack
9. 7-Pin S-Video-Out
Jack
10. DC-In Jack
11. Serial Port
7-Pin S-Video-Out Jack
The 7-pin S-Video Out
Jack requires an adapter
cable (7-pin S-Video plug
to 4-pin S-Video jack
adapter) in order to con-
nect to a standard S-Vid-
eo cable.
1 - 8 External Locator - Rear View
