Removing the Bluetooth Module

1. Turn off the computer, and turn it over remove the battery
2. Locate the bay cover , and remove screws
6
.
3. Remove the bay cover
6
4. Remove the screws -
7 8
5. Disconnect the cable and carefully separate the Bluetooth Module from the connector
10
6. Lift the Bluetooth Module
12
a.
1
2
3
6
4
5
(page 2 -
- .
1 5
.
and the bracket
9
(Figure c) up and off the computer.
b.
7
10
9
8
11
5).
.
11
c.
12
Removing the Bluetooth Module 2 - 9
Disassembly
Figure 5
Bluetooth Module
Removal
a. Remove the screws and
the cover.
b. Remove the screws and
the braket. Disconnect
the cable and the con-
nector from the blue-
tooth module.
c. Lift the bluetooth module
out.
6. Bay Cover
9. Bracket
12. Bluetooth Module
• 7 Screws
