EUROCOM M570U Service Manual page 37

5. Turn the release latch towards the unlock symbol
6
6. Carefully (it may be hot) lift the CPU
7. Reverse the process to install a new CPU.
8. When re-inserting the CPU, pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE IT!).
d.
Unlock
e.
to release the CPU.
7 up and out of the socket (Figure
6
7
The heat sink, and CPU area in
general, contains parts which are
subject to high temperatures. Allow
the area time to cool before remov-
ing these parts.
7e).
6
Unlock
Caution
Disassembly
Figure 7
Processor Removal
(cont'd)
d. Turn the release latch to
unlock the CPU.
e. Lift the CPU out of the
socket.
7. CPU
Removing the Processor 2 - 11
