Removing The Hard Disk Drive - EUROCOM M570U Service Manual

Disassembly

Removing the Hard Disk Drive

Figure 2
HDD Assembly
The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" serial (SATA II)
Removal
hard disk drives with a height of 9.5mm (h). Follow your operating system's installation instructions, and install all nec-
essary drivers and utilities (as outlined in Chapter 4 of the User's Manual) when setting up a new hard disk.
a. Remove the screws.
b. Remove the cover and lo-
Hard Disk Upgrade Process
cate the hdd.
1. Turn off the computer, and turn it over and remove the battery
2. Locate the component bay cover and remove screws
3. Remove the bay cover
4. The hard disk assembly cover will be visible at point
a.
12. Component Bay
Cover
13. HDD Assembly
Cover
• 11 Screws
2 - 6 Removing the Hard Disk Drive
.
12
c.
4
1 2 3
5
7
8
6
9
10
11
(page 2 - 5).
- .
1 11
on the mainboard.
13
b.
12
13
