Feature
Video Card ATI Mobility Radeon X1600 (M56)
Options PCI-Express Video Card
128MB DDR Video RAM On Board
PCI Express * 16
Supports DirectX® 9
Modular Design
Hyper Memory
Storage Options One 2.5" 9.5mm (h) Serial-ATA (SATA) Hard Disk Drive
One Changeable Device Bay For One of the Following Options:
For 12.7 mm (h) Optical CD/DVD Device Drive Options
OR
For Secondary 2.5" 9.5mm (h) Hard Disk Drive (RAID Option in SATA Configuration)
RAID 0, RAID 1, HDD Fault Tolerance System in SATA Configuration
OR
For 2nd Battery
Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo)
Note: MS Duo/ Mini SD/ RS MMC Cards Require a PC Adapter
Specification
NVIDIA GeForce Go 7900 GTX (G71M-U)
PCI-Express Video Card
256MB DDR-III (DDR3) Video RAM On Board
256 bit Memory Interface
PCI Express * 16
Supports WGF 1.0 (DirectX®10)
HDMI TV Output Support
Modular Design
Video Card Options
Note that card types, specifications and drivers are sub-
ject to continual updates and changes. Check with your
service center for the latest details on video cards sup-
ported.
(see"Optional" on page 1 - 5)
Introduction
System Specifications 1 - 3
