Removing The Bluetooth Module - EUROCOM M660N Service Manual

Disassembly

Removing the Bluetooth Module

Figure 10
Bluetooth Removal
1. Turn off the computer, remove the battery
2. The Bluetooth module will be visible at point
a. Remove the cover and
3. Carefully separate the module from the connector
locate the Bluetooth
4. Lift the Bluetooth module
module.
b. Seperate the connector
and disconnect the ca-
ble.
c. Remove Bluetooth mod-
ule.
4. Bluetooth Module
2 - 14 Removing the Bluetooth Module
(
Figure d
4
a.
1
b.
2
3
(page 2 - 5) and remove the hard disk bay cover
on the mainboard.
1
and disconnect the cable
2
)
up and off the computer.
c.
(page 2 - 6).
.
3
4
