Removing The Battery - EUROCOM D47EV Service Manual

Disassembly

Removing the Battery

1. Turn the computer off.
2. Remove screws
3. Carefully (use a small screwdriver) disconnect the battery cable at point
4. Lift the battery
5. When replacing the battery, connect the cable first.
Figure 1
Battery Removal
a.
a. Remove the 3 screws
and the battery cover.
b. Carefully disconnect the
battery cable.
c. Remove the battery.
4. Battery Cover
6. Battery
• 3 Screws
2 - 8 Removing the Battery
- (Figure 1a) from the battery cover
1 3
out of the computer.
6
2 3
1
, and remove the cover.
4
.
5
b.
4
c.
6
5
