Removing the Inverter

1. Turn off the computer and remove the battery
(page 2 - 12), Bluetooth module
and center cover (page 2 - 18), LCD assembly
2. Remove screws (and any rubber covers)
3. Run your finger around the middle of the frame to carefully unsnap the LCD front panel module
4. Remove screw from the inverter, then turn over the inverter and disconnect cables
8
5. Lift the inverter up off the LCD assembly.
11
a.
1 2 3
5
c.
8
(page 2 - 8), HDD (page 2 -
(page 2 - 14), WLAN module (page 2 -
(page 2 - 19) and top case module
- from the front of the LCD assembly.
1 6
b.
4
d.
6
e.
9), memory (page 2 - 10), CD device
15), processor (page 2 - 16), keyboard
(page 2 - 21).
.
7
& .
9 10
7
9 10
11
Disassembly
Figure 22
Inverter Removal
a. Remove the screws.
b. Remove the front panel
module.
c. Remove the screw on
the inverter.
d.Turn the inverter over
and disconnect the ca-
bles.
e. Remove the inverter.
7. Display Front Pan-
el Module
11. Inverter Module
• 7 Screws
Removing the Inverter 2 - 29
