- Page 3 Preface Notebook Computer D400V/D410V Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
-
Page 5: About This Manual
This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the D400V/ D410V series notebook PC. -
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, elec- tric shock and injury to persons, including the following: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. -
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 8: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel. -
Page 10: Related Documents
Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII... -
Page 11: Table Of Contents
Preface Contents Introduction ..........1-1 External Locator - Bottom View ............ 1-8 Mainboard Overview - Top (Key Parts) ......... 1-9 Overview ..................1-1 Mainboard Overview - Bottom (Key Parts) ......... 1-10 System Specifications ......... 1-2 Mainboard Overview - Top (Connectors) ........1-11 Processor Types ................1-2 Mainboard Overview - Bottom (Connectors) ....... - Page 12 Combo Drive (D400V) ..............A-9 PCMCIA ENE1410 ..............B-20 DVD-ROM Drive (D400V) ............A-10 PCMCIA Power & MDC Interface ..........B-21 Hard Disk Drive (D400V) ............A-11 1394 PHY TSB41LV01 ..............B-22 Top (D410V) ................A-12 LPC Super I/O ................B-23 Bottom (D410V) ................A-13 LPT/COM Port ................B-24...
- Page 13 Preface Mobility M10-P POW ..............B-36 VCORE ..................B-37 +1.2V, +1.5V ................B-38 +2.5V, +1.25V, +1.8V ..............B-39 +3V, +5V, +12V ................B-40 Charger ..................B-41 SW Board and HotKey ..............B-42 TouchPad and Switch Board ............B-43...
- Page 14 Preface...
-
Page 15: Introduction
1: Introduction Overview This manual covers the information you need to service or upgrade the D400V/D410V series notebook computer. Infor- mation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer. -
Page 16: System Specifications
Introduction System Specifications Feature Specification Processor Types Intel Pentium® 4 Processor (478-pin) FC-PGA2 Package (µ0.13) 0.13 Micron Process Technology, 512KB On-die L2 Cache & 800MHz Front Side Bus - 2.4 ~ 3.2 GHz Intel Pentium® 4 Processor (478-pin) FC-PGA2 Package (µ0.13) 0.13 Micron Process Technology, 512KB On-die L2 Cache &... -
Page 17: Hard Disk
Introduction Feature Specification Hard Disk Easy changeable 2.5" 9.5/12.7 mm (h) Hard Disk Drive Supports Master mode IDE Supports PIO mode 4, ATA-33/ 66/ 100/ 133, Ultra ATA Port PC Card One Type II PCMCIA 3.3V/5V socket supporting CardBus Keyboard “WinKey”... -
Page 18: Design Differences
Introduction Feature Specification Indicator LED indicators (Power On/ AC-In/ Suspend, Battery Charging/Battery Full, E-Mail, HDD, Num Lock, Caps Lock, Scroll Lock) Environmental Spec Temperature Relative Humidity Operating: 5°C ~ 35°C 20% ~ 80% Non-Operating: -20°C ~ 60°C 10% ~ 90% Physical Dimensions 329 (w) x 275 (d) x 36.5 (h) mm Weight... -
Page 19: External Locator - Top View
Introduction External Locator - Top View Figure 2 Top View 1. Optional Built-in PC Camera 2. LCD 3. Built-In Microphone 4. LED Power & Communication Indicators 5. LED Status Indicators 6. AP-Key buttons 7. Close Cover/Lid Switch 8. Power Button 9. -
Page 20: External Locator - Front & Left Side Views
Introduction External Locator - Front & Left Side Views Figure 3 Front View 1. LCD Latches 2. Mini IEEE 1394 Port 3. S/P DIF Out Port 4. Microphone Jack 5. Headphone Jack 6. Infrared Transceiver 7. Wireless Device ON/OFF Switch 8. -
Page 21: External Locator - Right Side & Rear Views
Introduction External Locator - Right Side & Rear Views Figure 5 Right Side View 1. Security Lock Slot Figure 6 Rear View 9 10 1. Vent 2. DC-In Jack 3. 2 * USB 2.0/1.1 Ports 4. External Monitor (CRT) Port 5. -
Page 22: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 7 Bottom View 1. Vent/Fan Intake 2. Battery Cover 3. Hard Disk Cover 4. Bluetooth Module Cover 5. CPU, Heatsink, DDR, Wireless LAN Cover Note : The RAM and optional Wireless LAN module are lo- cated under the CPU Heatsink Cover. -
Page 23: Mainboard Overview - Top (Key Parts)
Introduction Mainboard Overview - Top (Key Parts) Figure 8 Mainboard Top Key Parts 1. PC Card Assembly 2. Northbridge - SiS 648FX (839 mBGA) 3. Southbridge - SiS 963 (371 mBGA) 4. LAN Realtek RTL 8110S 5. VGA Chipset -ATI Mobility M10 6. -
Page 24: Mainboard Overview - Bottom (Key Parts)
Introduction Mainboard Overview - Bottom (Key Parts) Figure 9 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Memory Slots (no memory installed) 3. CardBus ENE 1410 4. ALC650 - Audio Codec 5. LPC - H8 6. LPC Super I/O NS PC87393 7. -
Page 25: Mainboard Overview - Top (Connectors)
Introduction Mainboard Overview - Top (Connectors) Figure 10 Mainboard Top Connectors 1. Modem Cable Connector (CN1) 2. LCD (and Inverter) Connector (JLCD1) 3. Video Camera Cable Connector (JCCD1) 4. Power Switch Board Cable Connector (JSW1) 5. TouchPad Cable Connector (JTP1) 6. -
Page 26: Mainboard Overview - Bottom (Connectors)
Introduction Mainboard Overview - Bottom (Connectors) Figure 11 Mainboard Bottom Connectors 1. Wireless LAN Connector (JWL1) 2. DDR Fan Cable Connector (JFAN3) 3. CD-ROM Device Connector (JCDROM1) 4. Hard Disk Cable Connector (JHDD1) 5. Bluetooth Module Connector (JBT1) 6. CMOS Battery Cable Connector (JBAT1) 7. -
Page 27: Disassembly
2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the D400V/D410V series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. -
Page 28: Maintenance Tools
Disassembly NOTE : All disassembly procedures assume that the system is turned OFF , and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 29: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 30: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Processor: 1. Remove the battery page 2 - 8 1. - Page 31 Disassembly To remove the TouchPad and Click Board: To remove the Modem: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
- Page 32 Disassembly To remove the Mainboard: To remove the Card Reader Assembly: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
- Page 33 Disassembly To remove the LCD Front Panel Module: To remove the PC Video Camera Module: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
-
Page 34: Removing The Battery
Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Remove screws & (Figure 1a) from the battery cover , and remove the cover. 3. Carefully (use a small screwdriver) disconnect the battery cable at point (Figure 4. -
Page 35: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual ) when setting up a new hard disk. -
Page 36: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting DDR 200/266 MHz. The main memory can be expanded up to 1024MB. The SO-DIMM modules supported are 128Mb, Heat Sink Unit 256Mb, and 512Mb. - Page 37 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket toward the sides of the computer. Figure 4 Removing/ Installing a RAM Module a. Pull release latches. b.Remove the module. 6. The module (Figure 4b) will pop-up, and you can remove it.
-
Page 38: Removing The Cd Device
Disassembly Removing the CD Device The easy changeable CD device may be upgraded or changed. 1. Turn off the computer, and remove the battery ( page 2 - 8 2. Remove screws (Figure 5a) from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- nect it). - Page 39 Disassembly 4. Use a screwdriver to carefully push the CD device assembly out of the computer at point Figure 6 CD Device Removal Push the CD device out off the computer at point 5. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The screw holes should line up.
-
Page 40: Removing The Bluetooth Module
Disassembly Removing the Bluetooth Module page 2 - 8 1. Turn off the computer, and remove the battery ( 2. Remove screws from the Bluetooth module cover 3. Carefully lift up the Bluetooth module cover off the computer. 4. Remove screws and carefully disconnect cables then remove the Bluetooth module Figure 7... -
Page 41: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module page 2 - 8 1. Turn off the computer, and remove the battery ( 2. Remove screws from the memory socket cover Figure 8 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- Wireless LAN nect it). -
Page 42: Removing The Processor
Disassembly Removing the Processor page 2 - 8 1. Turn off the computer, and remove the battery ( 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- Figure 9 nect it). - Page 43 Disassembly & 6. Remove screws and lift the CPU holder off the computer. 7. Unlock the processor by raising lever 8. Lift the CPU off the computer. Figure 10 Processor Removal (cont’d) a. Remove the screws and lift the CPU holder off the computer.
-
Page 44: Removing The Keyboard
Disassembly Removing the Keyboard page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you may need to use a small screwdriver to do this). -
Page 45: Removing The Keyboard Shielding Plate
Disassembly Removing the Keyboard Shielding Plate page 2 - 8 page 2 - 18 1. Turn off the computer, remove the battery ( ) and keyboard ( 2. Remove screws from the keyboard shielding plate and lift the plate off the computer. Figure 12 Keyboard Shielding Plate Removal... -
Page 46: Removing The Lcd And Top Case
Disassembly Removing the LCD and Top Case page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14... - Page 47 Disassembly 5. Slide the LCD hinge covers out of the computer. 6. Remove screws & then carefully (pay careful attention to the antenna cables) lift the LCD assembly the computer. & & 7. Remove screws and disconnect cables , then lift the top case assembly off the computer.
-
Page 48: Removing The Touchpad And Click Board
Disassembly Removing the TouchPad and Click Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14... -
Page 49: Removing The Led Board
Disassembly Removing the LED Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... -
Page 50: Removing The Modem
Disassembly Removing the Modem page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... -
Page 51: Removing The Speakers
Disassembly Removing the Speakers page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... -
Page 52: Removing The Mainboard
Disassembly Removing the Mainboard page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... -
Page 53: Removing The Fan Unit
Disassembly Removing the Fan Unit page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... -
Page 54: Removing The Card Reader Assembly
Disassembly Removing the Card Reader Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... -
Page 55: Removing The Pcmcia Assembly
Disassembly Removing the PCMCIA Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... -
Page 56: Removing The Lcd Front Panel Module
Disassembly Removing the LCD Front Panel Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14... -
Page 57: Removing The Inverter
Disassembly Removing the Inverter page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... -
Page 58: Removing The Pc Video Camera Module
Disassembly Removing the PC Video Camera Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14... -
Page 59: Removing The Lcd Panel
Disassembly Removing the LCD Panel page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (... - Page 60 Disassembly 2 - 34...
-
Page 61: Part Lists
Part Lists Appendix A:Part Lists This appendix breaks down the D400V/D410V series notebook’s construction into a series of illustrations. The compo- nent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 62: Part List Illustration Location
Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table 1 - 1 Part List Illustration Part D400V D410V Location page A - 3 page A - 12 page A - 4... -
Page 63: Top (D400V
Part Lists Top (D400V) Figure 1 Top (D400V) Top (D400V) A - 3... -
Page 64: Bottom (D400V
Part Lists Bottom (D400V) 無鉛 Figure 2 Bottom (D400V) 無鉛 A - 4 Bottom (D400V) -
Page 65: Lcd 14" (D400V
Part Lists LCD 14" (D400V) Figure 3 LCD 14" (D400V) LCD 14" (D400V) A - 5... -
Page 66: Lcd 15" (D400V
Part Lists LCD 15" (D400V) Figure 4 LCD 15" (D400V) A - 6 LCD 15" (D400V) -
Page 67: Cd-Rom Drive (D400V
Part Lists CD-ROM Drive (D400V) Figure 5 CD-ROM Drive (D400V) CD-ROM Drive (D400V) A - 7... -
Page 68: Cd-Rw Drive (D400V
Part Lists CD-RW Drive (D400V) Figure 6 CD-RW Drive (D400V) A - 8 CD-RW Drive (D400V) -
Page 69: Combo Drive (D400V
Part Lists Combo Drive (D400V) Figure 7 Combo Drive (D400V) Combo Drive (D400V) A - 9... -
Page 70: Dvd-Rom Drive (D400V
Part Lists DVD-ROM Drive (D400V) Figure 8 DVD-ROM Drive (D400V) A - 10 DVD-ROM Drive (D400V) -
Page 71: Hard Disk Drive (D400V
Part Lists Hard Disk Drive (D400V) Figure 9 HDD Drive (D400V) Hard Disk Drive (D400V) A - 11... -
Page 72: Top (D410V
Part Lists Top (D410V) Figure 10 Top (D410V) A - 12 Top (D410V) -
Page 73: Bottom (D410V
Part Lists Bottom (D410V) 無鉛 Figure 11 Bottom (D410V) 無鉛 無鉛 Bottom (D410V) A - 13... -
Page 74: Lcd 14" (D410V
Part Lists LCD 14" (D410V) Figure 12 LCD 14" (D410V) A - 14 LCD 14" (D410V) -
Page 75: Lcd 15" (D410V
Part Lists LCD 15" (D410V) Figure 13 LCD 15" (D410V) LCD 15" (D410V) A - 15... -
Page 76: Cd-Rom Drive (D410V
Part Lists CD-ROM Drive (D410V) Figure 14 CD-ROM Drive (D410V) A - 16 CD-ROM Drive (D410V) -
Page 77: Cd-Rw Drive (D410V
Part Lists CD-RW Drive (D410V) Figure 15 CD-RW Drive (D410V) CD-RW Drive (D410V) A - 17... -
Page 78: Combo Drive (D410V
Part Lists Combo Drive (D410V) Figure 16 Combo Drive (D410V) A - 18 Combo Drive (D410V) -
Page 79: Dvd-Rom Drive (D410V
Part Lists DVD-ROM Drive (D410V) Figure 17 DVD-ROM Drive (D410V) DVD-ROM Drive (D410V) A - 19... -
Page 80: Hard Disk Drive (D410V
Part Lists Hard Disk Drive (D410V) Figure 18 HDD Drive (D410V) A - 20 Hard Disk Drive (D410V) - Page 81 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the D400V/D410V notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table 1 Diagram - Page Diagram - Page Diagram - Page Schematic System Block Diagram - Page B - 2...
-
Page 82: Schematic Diagrams
Schematic Diagrams System Block Diagram TV-OUT NORTHWOOD CLOCK ATI M10P & GENERATOR PRESCOTT SOCKET - 478 PANEL 2/16/32 2/16/32 Host Bus DDRAM DDRAM DDR INTERFACE SiS 648FX TV-OUT ( SiS 302LV ) PAGE 10 VB-LINK 839 mBGA Sheet 1 of 42 PANEL CRT PORT System Block... - Page 83 Schematic Diagrams Socket 478 1 of 2 HD#[0..63] HD#[0..63] 5 VCC_CORE VIDPWRGD VIDPWRGD38 JCPU1A HA#[3..31] HD#0 HA#[3..31] HD#1 HD#2 HD#3 HA#31 HD#4 HA#30 HD#5 HA#29 HD#6 HA#28 HD#7 HA#27 HD#8 HA#26 HD#9 HA#25 HD#10 HA#24 HD#11 HA#23 HD#12 HA#22 HD#13 HA#21 HD#14 HA#20...
-
Page 84: Socket 478 & Itp 2
Schematic Diagrams Socket 478 & ITP 2 of 2 VCC_CORE 49.9_1% CPUGTLVREFA R324 CPUGTLVREFB R400 49.9_1% C338 C336 C415 R323 C399 C405 C492 R401 220P 220P 100_1% 220P 220P 100_1% CPU SIGNAL TERMINALION VCC_CORE VCC_CORE CLOSE TO CPU JCPU1B FERR# R368 4.7uH_SMD_30% 62_1%... -
Page 85: Clock Generator
Schematic Diagrams Clock Generator Main Clock Generator Damping Resistors Place near to the +3VS Clock Outputs By-Pass Capacitors Place near to the Clock FCM2012V121 CLOCK GEN (660) Outputs CLK_VCC3 VDDREF CPU-1 RP37 HCLK-CPU HCLK-CPU R395 49.9_1% HCLK-CPU 3 VDDZ CPUCLK0 CPU-2 C504 C505... -
Page 86: M648Fx-1 (Host/Agp) 1
Schematic Diagrams M648FX-1 (Host/AGP) 1 of 4 AAD18/AHSYNC 22(R) AAD30/BHSYNC 22(R) AAD18/AHSYNC VAHSYNC 10 AAD30/BHSYNC VBHSYNC 10 22(R) AAD17/AVSYNC AAD31/BVSYNC 22(R) AAD17/AVSYNC VAVSYNC 10 AAD31/BVSYNC VBVSYNC 10 AAD16/VADE AAD16/VADE 10,30 AAD27/VBDE AAD27/VBDE 10,30 HNCOMP R313 20_1% 22(R) VBCLK AAD28/VBCTL0 AAD28/VBCTL0 10,30 Rds-on(n) = 10 ohm AAD29/VBCTL1... -
Page 87: M648Fx-2 (Memory For Ddr) 2
Schematic Diagrams M648FX-2 (Memory for DDR) 2 of 4 /RMD[0..63] /RMD[0..63] 7,8 /RDQM[0..7] /RDQM[0..7] 7,8 /RDQS[0..7] /RDQS[0..7] 7,8 /RMA[0..14] /RMA[0..14] 7,8 /RCS#[0..5] /RCS#[0..5] 7,8 CKE[0..5] CKE[0..5] 7 Rs place close to DIMM1 0402 Package BGA1B +2.5V /RMD4 RP38 AN35 /RMD5 8P4R-10 AP36 DQM0... -
Page 88: M648Fx-3 & Crt Out 3
Schematic Diagrams M648FX-3 & CRT Out 3 of 4 BGA1C NOTE: This page is for universal PCB design( suitable for both 645 or 650) ZCLK0 ZCLK0 ZCLK REFCLK0 VOSCI REFCLK0 4 ZUREQ ZUREQ NB Hardware Trap Table ZUREQ ZDREQ ZDREQ ZDREQ embedded pull-low ROUT... -
Page 89: M648Fx-4 (Power) 4
Schematic Diagrams M648FX-4 (Power) 4 of 4 IVDD L124 FH50ACB321611T(R) C479 0.1UF +1.5VS +3VS +1.8VS 80 mil +1.8VS L123 FH50ACB321611T +1.8VS C529 0.1UF AUX_IVDD +1.8VS +1.8VS SUPPORT M660 BGA1D L126 0(R) +1.5V AB12 L127 10U(0805) 0.1UF AUX_IVDD +1.8V +1.8VS AC12 C456 AUX3.3 IVDD... -
Page 90: Ddr Memory Dimm
Schematic Diagrams DDR Memory DIMM +2.5V /RMA0 /RMD0 /RMA0 +2.5V /RMA1 /RMD1 /RMA1 /RMA2 /RMD2 /RMA2 RP18 /RMA3 /RMD3 /RMA3 CKE4 /RMA4 /RMD4 /RMA4 CKE2 /RMA5 /RMD5 /RMA5 CKE3 /RMA6 /RMD6 /RMA6 CKE5 /RMA7 /RMD7 /RMA7 /RMA8 /RMD8 /RMA8 8P4R-470(0402) /RMA9 /RMD9 /RMA9... -
Page 91: Ddr Sstl-2 Termination
Schematic Diagrams DDR SSTL-2 Termination SSTL-2 Termination Resistors MD/DQM(/DQS) SSTL-2 MA/Control SSTL-2 SSTL-2 OD 2.5V /RMD[0..63] /RMD[0..63]6,7 /RDQM[0..7] /RDQM[0..7]6,7 +1.25VS +1.25VS /RDQS[0..7] /RDQS[0..7]6,7 0402 Package /RMA[0..14] 0402 Package /RMA[0..14] 6,7 /RCS#[0..5] /RCS#[0..5] 6,7 /RMA2 /RMD0 /RMD1 /RMA0 /RMA12 /RDQS0 /RMD2 /RSRAS# /RSRAS# RP52... -
Page 92: Lvds Interface (Sis302Lv
Schematic Diagrams LVDS Interface (SiS302LV) C272 33PF(R) +3VS LVDD1 FCM1608K121(R) R259 C386 C385 FCM1608K-121T07 JTV2 10U/10V(R) 0.1UF 0.1UF LGND 2.7UH DA204U(R) DA204U(R) R260 C275 33PF(R) R252 C297 C273 C300 C276 330PF 330PF +3VS 330PF 330PF L100 LVDD2 SVIDEO CON PIN(GND1,GND2)=GND FCM1608K121(R) +3VS C348... -
Page 93: Panel Con & Led Indicator
Schematic Diagrams Panel Con & LED Indicator LCDVCC LCDVCC FCM2012V-121 FCM2012V-121 +3VS C350 C311 LCDVCC 60 mil 4800 JLCD1 0.1UF 0.1UF +3VS TXOUT-LN0 TXOUT-UN0 C352 C351 TXOUT-LP0 TXOUT-UP0 R288 4.7U(0805) 0.1UF TXOUT-UN1 C330 C331 TXOUT-LN1 TXOUT-LP1 TXOUT-UP1 R287 0.1UF 4.7U(0805) Z245 TXOUT-LN2 TXOUT-UN2... -
Page 94: Pci/Ide/Hyperzip) 1
Schematic Diagrams 963-1 (PCI/IDE/HyperZip) 1 of 4 AD[0..31] IDESAA[0..2] 19,20,25 AD[0..31] IDESAA[0..2] IDECS#A[0..1] IDECS#A[0..1] IDESAB[0..2] IDESAB[0..2] +1.8VS IDECS#B[0..1] IDECS#B[0..1] R519 BGA5A C191 C699 +3VS 0.01UF 0.1UF IDEAVDD REQ4# PREQ4# IDEAVSS REQ3# PREQ3# RP32 REQ2# ICHRDYA REQ2# ICHRDYA 14 FRAME# REQ1# PREQ2# ICHRDYA IDEREQA... -
Page 95: Misc Signals) 2
Schematic Diagrams 963-2 (Misc Signals) 2 of 4 Programable on-die pull-high strength for CPU_S: BGA5B ( Infinite, 150, 110, 56 Ohm) R166 4.7K OSC25MHI NEED NOT to place +3VS INIT# close to 96X INIT# INIT# OSC25MHO A20M# A20M# A20M# RN97 SMI# SMI# SMI#... -
Page 96: Usb I
Schematic Diagrams 963-3 (USB I/F) 3 of 4 BGA5C 1394_EECS GPIO24/EECS 1394_MA0/EEDO UCLK48M UCLK48M4 GPIO23/EEDO USBCLK48M 1394_MA1/EEDI GPIO22/EEDI 1394_MA2/EESK +DATA0 +DATA0 GPIO21/EESK UV0+ -DATA0 UV0- -DATA0 +DATA1 +DATA1 UV1+ -DATA1 -DATA1 UV1- +DATA2 PHY_LPS PHY_LPS +DATA2 PHY_REQ UV2+ -DATA2 PHY_REQ -DATA2 LREQ UV2-... -
Page 97: Power & Rtc) 4
Schematic Diagrams 963-4 (Power & RTC) 4 of 4 +1.8VS +1.8V +3VS C686 C687 C417 C499 C710 C650 C663 C678 C682 C711 C645 C653 C651 C679 C652 C661 0.1UF 0.1UF 10UF/10V 10UF/10V 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V +1.8VS BGA5D VDDZ... -
Page 98: Hdd/Combo Connector
Schematic Diagrams HDD/Combo Connector JCDROM1 CD-L CD-R CD-L CD-R CDGND CDGND IDERST# IDEDB8 IDEDB8 13 IDEDB7 IDEDB9 IDEDB7 IDEDB9 13 IDEDB6 IDEDB10 IDEDB6 IDEDB1013 +3VS IDEDB5 IDEDB11 IDEDB5 IDEDB1113 IDEDB4 IDEDB12 IDEDB4 IDEDB1213 R506 4.7K IDEDB3 IDEDB13 CBLIDB 13 IDEDB3 IDEDB1313 IDEDB2 IDEDB14... -
Page 99: Usb Port
Schematic Diagrams USB Port 560K OC0# OC0# USBVCC0 USBVCC0 FCM2012V121 10UF/10V 0.1UF C345 C317 0.1UF -DATA0 JCCD1 -DATA0 -DATA3 -DATA3 +DATA0 FCM1608K121 +DATA0 +DATA3 +DATA3 FCM1608K121 CCD CON NEAR CCD CON. C347 C346 47P(R) JUSB2 47P(R) USB-PLUG V+_OUT1 DATA_L1 DATA_H1 R255 560K PLW3216S161SQ2... -
Page 100: Pcmcia Ene1410
Schematic Diagrams PCMCIA ENE1410 B_VCC C811 C810 C789 C781 C780 C837 C802 C822 C779 C853 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 10UF/10V C809 C852 0.1UF 0.1UF JPCM1 B_VCC VPPD0 B_CD0 VPPD0 VPPD1 B_CD1 VPPD1 VCCD0# B_CD2 VCCD0# VCCD1# B_CD3 C235... -
Page 101: Pcmcia Power & Mdc Interface
Schematic Diagrams PCMCIA Power & MDC Interface C756 0.1UF JMDC1 +12V +3VS MONO_OUT AUDIO_PD PHONE MONO_PHONE PHONE AUXR B_VCC BVCC AUXL C765 BVCC CDGND C767 C768 R568 BVCC CD_R 0.1UF CD_L 0.1UF 4.7U(0805) 8.2K(R) P_DN VDD3 3.3V AC_SYNC AC_SYNC 15,26 3.3V SYNC AC_SDOUT... -
Page 102: 1394 Phy Tsb41Lv01
Schematic Diagrams 1394 PHY TSB41LV01 L145 BLM21P221SGPTM00-03 PHY3V L146 BLM21P221SGPTM00-03(R) +3VS C864 C872 C880 C889 C877 C878 C869 C873 0.01UF 0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF 4.7U(0805) R709 6.34K_1% Sheet 21 of 42 R708 1394 PHY PHY3V Z216 Z240 TSB41LV01 R696 1K(R) VDD5... -
Page 103: Lpc Super I/O
Schematic Diagrams LPC Super I/O +3VS C760 C754 C752 0.1UF 0.1UF 0.1UF +3VS SA10 SA11 SA12 PD[0..7] PD[0..7] 23 +5VS SA13 +5VS LPC_AD[0..3] R585 15,24 LPC_AD[0..3] SA14 SA15 LPC_AD0 LAD0 PD0/INDEX# SA16 LPC_AD1 LAD1 PD1/TRK0# FLASH# R591 LPC_AD2 LAD2 PD2/WP# BIOSCS# SA17 LPC_AD3... -
Page 104: Lpt/Com Port
Schematic Diagrams LPT/COM Port R724 0(R) VDD5 VDD3 C285 R725 0.1UF R285 100K PME# C270 PME# 19,22,24,25 0.1UF(K%) C307 C269 COM1RI 2N7002 C306 0.1UF(K%) 0.1UF(K%) JCOM1 1SS355 0.1UF(K%) R286 RN49 100K SOUTA SOUTA RTSA# T1IN T1OUT RTSA# T2IN T2OUT DTRA DTRA T3IN T3OUT... -
Page 105: Lpc H8
Schematic Diagrams LPC H8 VDD5 R651 0(0805)(R) 3VH8 3VH8 R650 0(0805) VDD3 C813 3VH8 4.7U(0805) C281 0.1UF +5VS C814 3VH8 1.1A F1AJ3 FH50ACB321611T C812 C804 C303 0.1UF 0.1UF RP70 0.1UF 0.1UF C838 C783 C782 C773 JPS1 KB-SI3 0.1UF 0.1UF 0.1UF 10UF/10V KB-SI2 KB-SI4... -
Page 106: Lan Rtl8110S(B)-32/Rtl8100C
Schematic Diagrams LAN RTL8110S(B)-32/RTL8100C LAN_DVDD F01J2E VDD3 LANVDD3 BK2125HS121(R) L120 LANVCC2.5 BK2125HS121 F01J2E LANVCC1.8 JLAN1 C353 C274 C302 C299 C312 C271 BK2125HS121 C394 C395 0.1U RING 10U(0805) 0.1U 10U/10V(0805) FCM1608K121 RING 10U(0805) 0.1U 0.1U 0.1U 0.1U FCM1608K121 MDC 2P PLW3216S161SQ2 V_DAC LAN_DVDD R720... -
Page 107: Audio Codec Alc650
Schematic Diagrams Audio Codec ALC650 L143 For some crystal, FCM1608K-121 VDDA +3VS the bias resistor is needed R642 C798 C801 C836 C831 1M(R) 0.1UF 0.1UF R630 10UF/10V 10UF/10V 0(R) AGND C833 LOUT-L 24.576MHz LOUT-R C800 C799 C834 60 mil 60 mil XTL-IN L148 XTL-OUT... -
Page 108: Audio Out & Off Board Connectors
Schematic Diagrams Audio Out & Off Board Connectors VDDA JAUDIO3 INTMIC R237 AUDIO_JACK INTMIC 2.2K(R) SPDIF/LINE-R C250 FCM1608K-121 SPDIF OUT SPDIF/LINE-R SPDIF/LINE-L 0.1UF FCM1608K-121 SPDIF/LINE-L C243 C248 C249 10UF/10V(R) R236 2.2K(R) 680P 680P JAUDIO2 BK1608HS330 AUDIO_JACK AGND MIC IN Vrefout R235 2.2K R238... -
Page 109: System Power Control
Schematic Diagrams System Power Control +2.5V +2.5VS 4800 U10B R589 U11B +12V U10C S3AUXSW# SUSB# 74LVC14 C758 SUSB# 13,24 PSON# R204 R203 15,29 PSON# U10D 10UF/10V 100K 74(A)HC08 330K C222 SLP S3 74LVC14 0.1UF PSON PSON# 74LVC14 PSON 29,40 2N7002 U10E U11C U10F... -
Page 110: Fan Control And Speedstep
Schematic Diagrams Fan Control and SpeedStep L135 FAN_VCC FCM2012V121 MAIN FAN C698 100U/16V DIP R546 H_DPSLP# JFAN2 24.9K H_DPSLP# 2,36 R545 F01J2E 4.7K FAN_SEN FAN_SEN R516 FI-S03P-HF 3904 CPUSTP# CPUSTP# 4,15 FAN1-ON C706 R509 1SS355 FAN1-ON 0.1UF 2SD1834 C660 0.1UF(R) R209 4.7K FAN_VCC_3... -
Page 111: Mobility M10-P
Schematic Diagrams Mobility M10-P AAD[0..15] +3VS 5,10 AAD[0..15] BGA2A AAD0 R113 AAD1 GPIO0 Part 1 of 6 R116 AAD2 GPIO1 AAD16/VADE AAD3 GPIO2 5,10 AAD16/VADE AAD17/AVSYNC AAD4 GPIO3 R114 R333 8.2K(R) R354 8.2K(R) AAD17/AVSYNC AAD18/AHSYNC AAD5 GPIO4 +3VS R474 AAD18/AHSYNC AAD27/VBDE AAD6 GPIO5... -
Page 112: Mobility M10-P Mem A/B
Schematic Diagrams Mobility M10-P MEM A/B DMAB[0..13] DMAB[0..13] DMAA[0..13] DMAA[0..13] OPTIONAL SERIES OPTIONAL SERIES TERMINATION TERMINATION FOR MEMORY FOR MEMORY ADDR & CNTRL ADDR & CNTRL INSTALL INSTALL RESISTORS RESISTORS MEMORY CHANNEL A CLOSER TO MEMORY CHANNEL B CLOSER TO DQMA#[7..0] DQMB#[7..0] DQMA#[7..0]... -
Page 113: Vga Ddr Dram Channel A
Schematic Diagrams VGA DDR DRAM Channel A +2.5V_MEM +1.25VS +2.5V_MEM MDA0 RN56 C465 0.1U MDA1 MDA2 MDA3 8P4R_56(0402) BGA6 BGA7 MDA5 RN57 0.1U 470P MDA4 56(0402) 56(0402) QSA0 DQMA#0 8P4R_56(0402) MEM_MAA0 MEM_CLKA0 MDA12 MEM_MAA1 MEM_CLKA0# MDA11 MEM_MAA2 MEM_CLKA1 DQMA#1 MEM_MAA3 MEM_CLKA1# QSA1 8P4R_56(0402) -
Page 114: Vga Ddr Dram Channel B
Schematic Diagrams VGA DDR DRAM Channel B +2.5V_MEM +1.25VS +2.5V_MEM C150 MDB6 RN87 C623 0.1U 470P MDB2 R128 56(0402) R127 56(0402) MDB7 MDB0 8P4R_56(0402) C131 BGA3 BGA4 MEM_CLKB0 DQMB#0 RN86 0.1U MDB5 MEM_CLKB0# MEM_CLKB1 MDB1 MEM_CLKB1# QSB0 8P4R_56(0402) MEM_MAB0 MDB8 C638 0.1U MEM_MAB1 R507... -
Page 115: Vga Ddr Dram Termination
Schematic Diagrams VGA DDR DRAM Termination MDB[63..0] 31,33 MDB[63..0] MEM_MDB[63..0] Close to memory device MEM_MDB[63..0] MDA[63..0] Close to memory device 31,32 MDA[63..0] MDB0 RN36 8P4R-10(0402) MEM_MDB0 MEM_MDA[63..0] MDB2 MEM_MDB2 MDA0 RN55 8P4R-10(0402) MEM_MDA0 MDB1 MEM_MDB1 MDA2 MEM_MDA2 MDB3 MEM_MDB3 MDA1 MEM_MDA1 MDB4 RN37... -
Page 116: Mobility M10-P Pow
Schematic Diagrams Mobility M10-P POW BGA2F VDDC Part 6 of 6 VDDC 655mA BGA2D +3VS DIODE SUPPLIES POWER VDDC +2.5V_MEM VDDR1 TO VDDC RAIL VDDC Part 4 of 6 VDDR1(CLKBFB) WHEN VDDC IS OFF AND +3.3V IS ON VDDC VDDR1 VDDC C655 C583... -
Page 117: Vcore
Schematic Diagrams VCORE VCC5_DRV VCC5_DRV PD22 FS1J3 TEST_C H_DPSLP# VCC_CORE PC108 PD23 0.47U/25V(0805) PR13 PR14 PR15 AUX3 AUX1 AUX2 40.2K 1% 40.2K 1% 40.2K 1% RB751V PR69 PC21 PC25 10U/25V PC97 CPU_PSC_HI PR11 15nF 301 1% PC107 PR66 PC22 PC20 10U/25V PC117 PC116... -
Page 118: V, +1.5V
Schematic Diagrams +1.2V, +1.5V SYS5V PR41 PR42 PC154 PC50 RB751V PD15 RB751V PC56 PC55 0.1uF/25V 10U_1210 PC158 1000P PGOOD1 PGOOD2 PC142 1000P VDDP1 VCCA1 PC156 PC53 VDDP2 VCCA2 PC49 PC54 0.1uF/25V Sheet 37 of 42 PQ26 PR35 10U_1210 TON1 1.5V IRF7811AV PR135 ILIM1... -
Page 119: V, +1.25V, +1.8V
Schematic Diagrams +2.5V, +1.25V, +1.8V VDDP SYS5V PR129 PR130 PC57 PC67 PD36 RB751V PD37 RB751V PC41 PC45 PC40 0.1uF/25V 10U_1210 10U_1210 PC165 1000P PGOOD1 PGOOD2 PC58 1000P VCCA1 PQ17 IRF7811AV VDDP1 VCCA2 2.5V PC64 PC145 PR133 PC44 0.1uF/25V ILIM1 TON1 2.0UH PR139 20K 1%... -
Page 120: 5V, +12V
Schematic Diagrams +3V, +5V, +12V PR160 VIN1 PC78 PC76 0.1A 12VR 0.1U 10U/25V PC83 PC82 PC175 PC74 0.1U 10U/25V 0.1U PD16 PC73 PC168 10U/16V PD21 PC84 RB751V 0.1U 1U/50V_0805 11FS2 10U_1210 PC72 PD17 PQ59A 0.1U RB751V AO4900 PC174 BST3 0.1U VDD3 SYS3V PR116... -
Page 121: Charger
Schematic Diagrams Charger F1J3FTP PQ54 2.5A Si4435 2.5A PC32 PC125 PC31 PR100 PD30 0.1U 10U_1210 0.1U PQ13 Si4435 PQ19 CDRH-1205-470 100m(2512) 03A04 DTA114EUA PC129 PC137 PC136 PR27 PD28 PC138 PC134 PC42 1N4148 10U/25V_DIP F1J3FTP 0.1U(0805) 0.1U(1206) 100K 100U/25V_DIP 100U/25V_DIP 0.1U(1206) PR105 PR101 PQ18... -
Page 122: Sw Board And Hotkey
Schematic Diagrams SW Board and HotKey VSW2 LID_SW#_10 VCN1 VIN_10 VIN_10 MPU-101-81 PWRS_10 PWRS_10 LID_SW#_10 LID_SW#_10 WEB0#_10 WEB0#_10 0.1U WEB1#_10 WEB1#_10 WEB2#_10 WEB2#_10 Sheet 41 of 42 GND_L GND_L CON8 SW Board and HotKey GND_L Hot keys,Power switch,key,Lid VIN_10 VSW1 PWRS_10 HCH STS-05-A 0.1U... -
Page 123: Touchpad And Switch Board
Schematic Diagrams TouchPad and Switch Board VCC5_T 10MIL VCC5_T VCN3 10MIL VCN2 TPADDATA TPADCLK TPADDATA TPADCLK 10MIL SW_UP TP_FFC4-R SW_DOWN SW_L 0.1U SW_R 120P Sheet 42 of 42 120P 120P 0(R) TouchPad and plan GND_A GND_A Switch Board C178D83N C178D83N GND_A GND_A GND_A... - Page 124 Schematic Diagrams B - 44...
Need help?
Do you have a question about the D400V and is the answer not in the manual?
Questions and answers
