Removing the LCD Assembly

1. Turn off the computer and remove the battery
(page 2 - 12), Bluetooth module
board and center cover (page 2 -
2. Remove screws - from the bottom of the computer
1 13
3. Remove screws - from the rear of the computer
14 17
a.
1
13
12
11
b.
14
(page 2 - 8), HDD
(page 2 - 14), WLAN module (page 2 -
18).
.
.
2 2 4
10
9
(page 2 - 9), memory (page 2 - 10), CD device
15), processor (page 2 - 16) and the key-
5
6
8 7
16
Removing the LCD Assembly 2 - 19
Disassembly
Figure 12
LCD Assembly
Removal
a. Remove the screws from
the bottom of the compu-
ter.
b. Remove the screws from
the rear of the computer.
• 17 Screws
17
