Disassembly
Removing the Keyboard & Center Cover
1. Turn off the computer and remove the battery
2. Press the four keyboard latches
(you may need to use a small screwdriver to do this).
3. Carefully lift the keyboard up and disconnect the keyboard ribbon cable at point
board ribbon cable).
4. Set the keyboard
plate
5. Remove the center cover
Figure 11
Keyboard & Center
a.
Cover Removal
a. Press in the keyboard
latches and elevate the
keyboard.
1
b. Disconnect the keyboard
cable.
c. Lift the keyboard up and
out of the computer.
d. Remove the screws from
shielding plate.
e. Remove the shielding
d.
plate.
f. Carefully lift up the cent-
er cover off the compu-
7
ter.
18
6. Keyboard
19. Shielding Plate
20. Center Cover
• 12 Screws
2 - 18 Removing the Keyboard & Center Cover
-
1
aside and remove screws
6
.
19
.
20
2 3 4
10 11
8 9
15
16
12
13
17
14
(page 2 - 8).
at the top of the keyboard to elevate the keyboard from its normal position
4
- from the keyboard shielding plate, and lift off the shielding
7 18
b.
5
e.
19
(be careful not to bend the key-
5
c.
6
f.
20
