6. Remove screws and lift the CPU holder
1 2
7. Unlock the processor by raising lever
8. Lift the CPU off the computer.
5
a.
1
3
c.
5
off the computer.
3
.
4
3
2
b.
4
Caution
The heat sink, and
CPU area in general,
contains parts which
5
are subject to high
temperatures. Allow
the area time to cool
before removing these
parts.
Removing the Processor 2 - 17
Disassembly
Figure 10
Processor Removal
(cont'd)
a. Remove the screws and
lift the CPU holder off the
computer.
b. Raise the lever to unlock
the CPU.
c. Lift the CPU off the sock-
et.
3. CPU Holder
5. CPU
