EUROCOM D47EV Service Manual page 52

Disassembly
Removing the Sub Woofer
1. Turn off the computer and remove the battery
(page 2 -
and center cover
and mainboard
2. Remove screws
Figure 19
Sub Woofer
Removal
a. Remove the screws.
b. Lift out the sub woofer.
5. Sub Woofer
• 4 Screws
2 - 26 Removing the Sub Woofer
12), Bluetooth module (page 2 -
(page 2 - 18), LCD assembly
(page 2 - 25).
- and lift out the sub woofer
1 4
a.
1
2
(page 2 - 8), HDD (page 2 - 9), memory
14), WLAN module (page 2 - 15), processor
(page 2 - 19), top case module
.
5
b.
4
5
3
(page 2 - 10), CD device
(page 2 - 16), keyboard
(page 2 - 21), modem (page 2 - 24)
5
