Disassembly

Removing the PCMCIA Module

1. Turn off the computer and remove the battery
(page 2 -
and center cover
and mainboard
2. Carefully push the pins
3. Remove the PCMCIA module
Figure 21
PCMCIA Module
Removal
a. Push the pins to release
the PCMICA module.
b. Remove the PCMCIA
module.
3. PCMCIA Module
2 - 28 Removing the PCMCIA Module
12), Bluetooth module (page 2 -
(page 2 - 18), LCD assembly
(page 2 - 25).
- on the PCMCIA module as indicated.
1 2
from the mainboard.
3
a.
b.
3
(page 2 - 8), HDD (page 2 - 9), memory
14), WLAN module (page 2 - 15), processor
(page 2 - 19), top case module
1
2
(page 2 - 10), CD device
(page 2 - 16), keyboard
(page 2 - 21), modem (page 2 - 24)
