Removing the LED Board

1. Turn off the computer and remove the battery
(page 2 - 12), Bluetooth module
and center cover (page 2 - 18), LCD assembly
2. Remove screws & .
1 2
3. Carefully lift the LED board
3
a.
b.
(page 2 - 8), HDD
(page 2 - 14), WLAN module (page 2 -
(page 2 - 19), and top case module
off the top case module.
1
3
(page 2 - 9), memory (page 2 - 10), CD device
15), processor (page 2 - 16), keyboard
(page 2 - 21).
2
Disassembly
Figure 16
LED Board Removal
a. Remove the screws.
b. Lift the LED board off the
top case module.
3. LED Board
• 2 Screws
Removing the LED Board 2 - 23
