Feature
Hard Disk Easy Changeable 2.5" 9.5/12.7 mm (h) Hard Disk Drive
Supports Master mode IDE, PIO mode 4, ATA-33/ 66/ 100/ 133, Ultra ATA Port

PC Card

One Type II PCMCIA 3.3V/5V socket supporting CardBus

Keyboard

"WinKey" keyboard, Full-size with numeric pad
Pointing Device Built-in TouchPad (scrolling key functionality integrated)

Audio

AC'97 compliant interface
3D stereo enhanced sound system
Compatible Sound-Blaster PRO™
S/PDIF Digital output (5.1 CH)

Interface

Two USB 2.0 Ports
One Mini-IEEE 1394 Port
One S-Video out port for TV output
One serial port
One parallel port (LPT1)
One infrared transceiver supporting IrDA 1.1/ FIR/SIR/
ASKIR
One consumer infrared transceiver which functions with
the optional TV Tuner
One external monitor (VGA) port
One PS/2 Port
One headphone-out jack
One microphone-in jack

Communication

56K Plug & Play modem (V.90 & V.92 Compliant)
Infrared transfer: 115.2K bps SIR/ 4M bps FIR, IrDA 1.1 compliant
802.11b wireless LAN module (option)
PC Camera module (factory option)
Bluetooth module (option)
1000Base-T (Gigabit) LAN on-board (10/ 100 Base-T compatible)
*Do not try to use Bluetooth & TV Tuner at the same time, as this may cause configuration conflicts.

Power Management

Supports ACPI v1.0b
Supports Standby / Hibernate mode
Specification
Built-in microphone
4 Built-in speakers
Built-in sub woofer (factory option)
One RJ-11 jack for modem
One RJ-45 jack for LAN
One DC-in jack
One S/PDIF out port
3 Built-in hot-key buttons: WWW, E-Mail, & application
One S-Video-In port for video input (option with TV
Tuner module)
One Line-In port for audio input (option with TV Tuner
module)
One CATV-In port (option with TV Tuner module)
Supports Battery low suspend
Supports resume from modem ring
Introduction
System Specifications 1 - 3
