EUROCOM D47EV Service Manual page 53

Removing the Card Reader Assembly
1. Turn off the computer and remove the battery
(page 2 - 12), Bluetooth module
and center cover (page 2 - 18), LCD assembly
and mainboard (page 2 - 25).
2. Remove screws - and lift out the card reader
1 2
a.
(page 2 - 8), HDD (page 2 -
(page 2 - 14), WLAN module (page 2 -
(page 2 - 19), top case module
.
3
b.
1
3
2
9), memory (page 2 - 10), CD device
15), processor (page 2 - 16), keyboard
(page 2 - 21), modem (page 2 -
3
Removing the Card Reader Assembly 2 - 27
Disassembly
24)
Figure 20
Card Reader
Assembly Removal
a. Remove the screws.
b. Lift out the card reader.
3. Card Reader
• 2 Screws
