Removing the Top Case Module

1. Turn off the computer and remove the battery
(page 2 - 12), Bluetooth module
and center cover (page 2 - 18) and LCD assembly
2. Release the connectors -
1
3. Carefully lift the top case module
a.
1
b.
10
(page 2 - 8), HDD
(page 2 - 14), WLAN module (page 2 -
(page 2 - 19).
.
and remove screws -
4 5 8
off the bottom case .
9 10
5 6
3
2
4
(page 2 - 9), memory (page 2 - 10), CD device
15), processor (page 2 - 16), keyboard
7
8
9
Removing the Top Case Module 2 - 21
Disassembly
Figure 14
Top Case Module
Removal
a. Remove the screws and
release the connectors.
b. Carefully lift the top case
module off the bottom
case.
10. Bottom Case
9. Top Case
• 4 Screws
