EUROCOM D870P MIRAGE User Manual

Hide thumbs Also See for D870P MIRAGE:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D870P MIRAGE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EUROCOM D870P MIRAGE

Summary of Contents for EUROCOM D870P MIRAGE

  • Page 3: Trademarks

    Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifi- Power Safety cations, consult your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and the Troubleshooting chapter. Keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Preface Contents LCD Panel ............1-7 Microphone ............1-7 Notice ................I LED Power, Battery & E-Mail Status Indicators . 1-7 Trademarks ............. I Close Cover Switch ..........1-7 FCC Statement ............II LED Status Indicators ........... 1-8 Instructions for Care and Operation ....IV Hot-Key Buttons ...........
  • Page 16 Preface Vent/Fan Intake ...........1-17 LED Indicators ............2-5 DC-In Jack ............1-17 LED Power, Battery & E-Mail Status Indicators .. 2-6 Printer/Parallel Port ..........1-18 LED Status Indicators ..........2-7 DVI-Out Port ............1-18 Auto Mail Checker ........... 2-8 Serial/Com Port ...........1-18 Special Group ............. 2-10 Two USB 2.0/1.1 Ports ........1-19 The Hard Disk Drive ..........
  • Page 17 Preface Overview ..............3-1 Battery Life ............3-24 Advanced Video Controls ........3-2 Battery FAQ ............3-25 Opening the LCD ...........3-2 Configuring the Infrared Settings for FIR ..... 3-26 Video Driver Controls ..........3-3 Drivers & Utilities ......4-1 Making Adjustments for the Display .....3-4 Overview ..............
  • Page 18 Preface Upgrading The Computer ...6-1 Windows XP ............4-11 New Hardware Found ..........4-11 Overview ..............6-1 Chipset (WinXP) ..........4-12 When Not to Upgrade ..........6-2 Audio (WinXP) ...........4-13 Battery Removal ............6-3 Modem (WinXP) ..........4-13 Upgrading the CD/DVD Device (Bay Two) ... 6-4 LAN (WinXP) .............4-14 Upgrading the Hard Disk(s) ........
  • Page 19 Preface Audio Setup ............7-13 AMCAP ..............7-15 RAID Configuration ..........7-17 Jumper Setting for RAID/ATA Configuration ..7-18 RAID Setup ............7-19 Troubleshooting ......8-1 Overview ..............8-1 Basic Hints and Tips ..........8-2 Backup and General Maintenance ......8-3 Viruses ..............8-4 Upgrading and Adding New Hardware/Software ..8-5 Power ................8-7 Display ..............8-9 Boot Password ............8-10...
  • Page 20 Preface XVIII...

  • Page 21: Introduction

    Introduction Chapter 1: Introduction The Manual Notes This manual refers to the hardware and essential software required to run your Check the light colored boxes with the mark computer. Depending on how your system is configured, some or all of the above to find detailed features described may already be set up.

  • Page 22: Warning Boxes

    Introduction Warning Boxes No matter what your level please pay careful attention to the warning and safe- ty information indicated by the symbol. Also please note the safety and handling instructions as indicated in the Preface . Not Included Operating Systems (e.g. Windows 2000 Professional, Windows XP etc.) have their own manuals, as do applications (e.g.

  • Page 23: Quick Start Guide

    Introduction Quick Start Guide This guide assumes that you are already familiar with computers and can tell Peripheral Devices at a glance what and where all the key components are. If you are not that com- fortable with this type of device, then please refer to the following pages, Please note that pe- which give an overview of the system.

  • Page 24: System Map

    Introduction System Map Your computer has a lot of built-in features. Most of these are enabled by your operating system. Further explanations of the various subsystems are covered in the chapter or pages indicated. Getting to Know Your Computer The following graphics will help you to become familiar with the basic func- tions, and to learn the location of the various ports and components of your computer.

  • Page 25: Top View

    Introduction Top View Figure 1 - 1 Top View with LCD Panel Closed LCD Latch LED Power, Battery & E-Mail Status Indicators To open the LCD display: Place the computer on a stable surface. Move the LCD latches in the direction of the arrows to release the top cover.

  • Page 26: Top View With Lcd Panel Open

    Introduction Top View with LCD Panel Open Figure 1 - 2 Top View with LCD Panel Open Built-In PC Camera (Optional) Built-In Microphone LED Power, Battery & E-Mail Status Indicators Close Cover Switch LED Status Indicators Hot-Key Buttons Power Button Keyboard 10.

  • Page 27: Pc Camera

    Introduction PC Camera If you have purchased the optional PC Camera, make sure you install the soft- ware application (see “PC Camera” on page 7 - 11). LCD Panel The computer comes with a TFT LCD (Liquid Crystal Display) screen, (see “LCD”...

  • Page 28: Led Status Indicators

    Introduction LED Status Indicators These display the system’s operational status. Refer to “LED Status Indica- tors” on page 2 - 7 for more information on what the lights mean. Hot-Key Buttons To learn how to set the buttons see “Hot-Key Buttons” on page 2 - Power Button Press this button to turn your computer on or off (see “Turning on the Com-...

  • Page 29: Keyboard

    Introduction Keyboard The computer has a “Win Key” keyboard including a numeric keypad. It has the same features as a full-sized desktop keyboard and can easily be replaced with a different language keyboard should you desire. Stereo Speakers Two built-in speakers provide rich, stereo sound. TouchPad &...

  • Page 30: Front View

    Introduction Front View Figure 1 - 3 Front View LCD Latches 3 4 5 Mini-IEEE 1394 Port S/PDIF Out Port Microphone-In Jack Headphone-Out Jack Mini-IEEE 1394 Infrared The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. Transceiver Built-In Speakers Mini-IEEE 1394 Port This allows high-speed connection to various peripheral devices, e.g.

  • Page 31: Microphone-In Jack

    Introduction Microphone-In Jack Record on your notebook computer with an external microphone. Headphone-Out Jack Headphones/speakers may be connected through this jack. Note: Set your sys- tem’s volume to a reduced level before connecting to this jack. Infrared Transceiver The infrared transceiver enables communication between the computer and another similarly equipped device, and is 4M bps FIR, IrDA 1.1 compliant.

  • Page 32: Left Side View

    Introduction Left Side View Figure 1 - 4 Left Side View Bay Two - CD/ DVD Device Bay PC Card Slot PC Card Slot Eject Button CD/DVD Device Bay (Bay Two) USB 2.0/1.1 Port A 5.25" CD/DVD device (12.7mm height) is standard depending on the model Bay One - you purchased.

  • Page 33: Usb 2.0/1.1 Port

    Introduction USB 2.0/1.1 Port This USB 2.0 compatible port (USB 2.0 is fully USB 1.1 compliant) is for low-speed peripherals such as keyboards, mice or scanners, and for high- speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 34: Bay One Options

    Introduction Bay One Options Bay One may contain one of the following optional modules: Operating System Sub Woofer Module Installation Warning The sub woofer module enhances the audio output with a deep precise bass sound. If you are installing an Op- erating System (e.g.

  • Page 35: Right Side View

    Introduction Right Side View Figure 1 - 5 Right Side View Bay Three - Optional for TV- Tuner OR Sub Woofer Bay Three Options Security Lock Slot Bay Three may contain one of the following optional modules: TV Tuner Module With the TV tuner installed you can watch TV, video conference and capture still and video images on your computer.

  • Page 36: Security Lock Slot

    Introduction Sub Woofer Module The sub woofer module enhances the audio output with a deep precise bass sound. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. 1 - 16 Right Side View...

  • Page 37: Rear View

    Introduction Rear View Figure 1 - 7 Rear View Vent/Fan Intake DC-In Jack 7 8 9 10 Printer/Parallel Port DVI-Out Monitor Port Overheating Serial/Com Port To prevent your computer from overheating make sure nothing blocks the vent/fan 2 * USB Ports intakes while the computer is in use.

  • Page 38: Printer/Parallel Port

    Introduction Printer/Parallel Port This port supports ECP (Extended Capabilities Port) and EPP (Enhanced Par- allel Port) 1.7/1.9 modes. DVI-Out Port The DVI-Out (Digital Video Interface) Port allows you to connect an external monitor, or Flat Panel Display, to allow dual video or simultaneous display on the LCD and external monitor/FPD (see “Attaching a Monitor”...

  • Page 39: Two Usb 2.0/1.1 Ports

    Introduction Two USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high- speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 40: S-Video-Out Port

    Introduction S-Video-Out Port Connect your television to your computer and view DVDs, VCDs or anything else your computer can display. You will need an S-Video cable to make the connection. Enable this port from the video driver controls (see “Enabling TV Display”...

  • Page 41: Bottom View

    Introduction Bottom View Figure 1 - 8 Bottom View Vent/Fan Intake CPU/RAM Cover Battery Hard Disk/WLAN Module/Bluetooth Module Cover Overheating The CPU is not a user To prevent your computer from overheating make sure nothing blocks the vent/fan serviceable part. intakes while the computer is in use.

  • Page 42: Battery

    Introduction Battery “Battery” on page 2 - 3 for instructions on battery use and care. Drive Warning Hard Disk Drive Don’t try to remove the The hard disk drive is used to store your data. You can have up to two hard hard disk (HDD) while disks in your computer depending on the configuration options purchased.

  • Page 43: Wireless Lan (Network) & Bluetooth Modules

    Introduction Wireless LAN (Network) & Bluetooth Modules Your notebook computer may have an optional Wireless Network module and/or Bluetooth module(s). If included, the antenna and other components Wireless Device are not externally visible (please check with your service representative). If Operation Aboard your configuration includes either wireless module, make sure you install the Aircraft...
  • Page 44 Introduction 1 - 24...

  • Page 45: Using The Computer

    Using The Computer Chapter 2: Using The Computer Overview To learn more about using your computer, please read this chapter. This chapter includes: • The Power Sources • Turning on the Computer • LED Indicators • Auto Mail Checker • The Hard Disk Drive •...

  • Page 46: The Power Sources

    Using The Computer The Power Sources The computer can be powered by either an AC adapter or a battery pack. Shutdown AC Adapter Please note that you Use only the AC adapter that comes with your computer. The wrong type of should always shut...

  • Page 47: Battery

    Using The Computer Battery The battery allows you to use your notebook computer while you are on the road or an electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before recharging.

  • Page 48: Turning On The Computer

    Using The Computer Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel. Power Button as Standby or Hibernate Button When the computer is on, you can use the power button as a hot-key button when it is pressed for less than 4 seconds.

  • Page 49: Led Indicators

    Using The Computer LED Indicators There are two sets of LED indicators (LED Power, Battery & E-Mail Status Indicators and LED Status Indicators) on your computer that will display helpful information about the current status of the computer. Figure 2 - 1 LED Power, Battery &...

  • Page 50: Led Power, Battery & E-Mail Status Indicators

    Using The Computer LED Power, Battery & E-Mail Status Indicators Icon Color Description Low Battery Warning Green The computer is on When the battery is critically low, immedi- Blinking Green The computer is in Standby mode ately connect the AC adapter to the comput- Orange The battery is being charged...

  • Page 51: Led Status Indicators

    Using The Computer LED Status Indicators Once your computer is on and in use, the LED status indicators will display the system's operational status. Scroll Lock To enable and disable the Scroll Lock feature, press ScrLk keys simultane- Icon Color Description ously.

  • Page 52: Auto Mail Checker

    Using The Computer Auto Mail Checker “What to After you have installed the driver for the Auto Mail program (see Install” on page 4 - 1 ) you may then configure it to give you notification when you receive new mail. You must be online to receive this notification (note that this program only supports the POP3 protocol), and your default mail program does not need to be open.
  • Page 53 Using The Computer You may then configure the options for your mailserver, name, password, pro- gram and method(s) of notification. Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages.

  • Page 54: Special Group

    Using The Computer Special Group You may add the e-mail addresses of those you wish to assign to your special group here. The Mail LED will then blink fast when mail is received from members of this group, if LED notification is enabled in the control panel (Figure 2 - Figure 2 - 5 Special Group Setup...

  • Page 55: The Hard Disk Drive

    Using The Computer The Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk is mounted in a removable case and can be taken out to accommodate other Power Safety 2.5" IDE hard disk drives with a height of 9.5 mm. You may have a second Before attempting to hard disk depending on the configuration purchased (see “Jumper Settings...

  • Page 56: The Cd/Dvd Device

    Using The Computer The CD/DVD Device There is a bay for a 5.25" CD/DVD device (12.7mm height). The actual device will depend on the model you purchased (see “Storage” on page A - 2). The Sound Volume Adjustment CD/DVD Device is usually labeled drive "D:" and may be used as a boot de- vice if properly set in the BIOS (“Boot Menu”...

  • Page 57: Handling Cds Or Dvds

    Using The Computer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/ Media Warning DVDs can be accessed. When manually eject- Remember to: ing a CD/DVD, DO NOT use a sharpened...

  • Page 58: Dvd Regional Codes

    Using The Computer DVD Regional Codes DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This can- not be altered even if you change your operating system or you use the module in another computer.

  • Page 59: Changing Dvd Regional Codes

    Using The Computer Changing DVD Regional Codes Go to the Control Panel in WindowsXP/Windows 2000 and double-click Sys- tem > Hardware (tab), click Device Manager, then click the + next to DVD/ CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties menu, and select the DVD Region (tab) to bring up the control panel as seen in “DVD Regional Codes (Windows XP)”...

  • Page 60: The Pc Card Slot

    Using The Computer The PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for a Type II PC Card. Inserting and Removing PC Cards • Align the PC Card with the slot and push the PC Card in until it locks into place.

  • Page 61: Hot-Key Buttons

    Using The Computer Hot-Key Buttons These keys access the internet, e-mail or a user-defined application with one quick button press. To use the “user-defined Hot-Key”, you must install the “What to Install” Hot-Key driver. After installing the Hot-Key driver (see on page 4 - 1 ), you may have to configure or change the settings.
  • Page 62 Using The Computer To configure and specify an application for Application 1 (the default Hot- Key setting is for the CD Player/Media Player application), you must follow the instructions below. Application.exe Right click the Hot-Key driver icon on the taskbar and the following You will need to locate menu will appear.

  • Page 63: The Function Keys And Numeric Keypad

    Using The Computer The Function Keys and Numeric Keypad Function Keys Other Keyboards On the bottom-left of the keyboard is the Fn key or Function key. The Fn key allows you to change operational features instantly. To use the following func- If your keyboard is tions press and hold the Fn key, then press the appropriate function key (Esc, damaged or you just...

  • Page 64: Numeric Keypad

    Using The Computer Numeric Keypad The keyboard has a numerical keypad for easy numeric data input (see “The Function Keys and Numeric Keypad” on page 2 - 19). Special Characters Activate the Number Lock feature by pressing the NumLk key at the top Some software appli- cations allow...

  • Page 65: Touchpad And Buttons/Mouse

    Using The Computer TouchPad and Buttons/Mouse The TouchPad is a device for pointing (controlling input positioning) on the Mouse Driver computer’s display screen by sensing finger movement, and downward pres- sure. It is an alternative to the mouse, however, you can also add a mouse to If you are using an ex- your computer either through the PS/2 interface, or one of the USB ports.
  • Page 66 Using The Computer Easy Launcher You can add programs to the menu from the Others Mouse control panel. Click on Settings for Easy Launcher to get the settings options. Click the New button and browse to Open any programs you wish to add to the menu.

  • Page 67: Adding A Printer

    Using The Computer Adding a Printer The most commonly used peripheral is a printer. The following conventions will help you to add a printer, however it is always best to refer to the printer Parallel Printer manual for specific instructions and configuration options. After setting up the printer attach the paral- USB Printer...
  • Page 68 Using The Computer 2 - 24...

  • Page 69: Advanced Controls

    Advanced Controls Chapter 3: Advanced Controls Overview This chapter covers: Drivers • Advanced Video Controls • Power and Battery Management Features You are unable to use most advanced con- • Configuring the Infrared Settings for FIR trols until the neces- sary drivers utilities are properly in-...

  • Page 70: Advanced Video Controls

    Advanced Controls Advanced Video Controls This section is about making adjustments for the LCD, and switching display devices. Protecting the LCD Do not allow any for- Opening the LCD eign objects (i.e. paper As you open the lid, adjust it so you can look at the screen straight on, without or plastic) to get be- tween the lid/LCD and any glare.

  • Page 71: Video Driver Controls

    Advanced Controls Video Driver Controls The video interface lets you change the screen resolution and color output to whatever is most comfortable/efficient for you. This is a matter of hardware, Screenshots video memory and the driver for your operating system. The driver interface All screenshots in this shows the available options (see “LCD”...

  • Page 72: Making Adjustments For The Display

    Advanced Controls Making Adjustments for the Display The higher the resolution you set the LCD for, the more information the LCD can display on screen. To change the LCD’s resolution and color depth go to Screen Resolution/ the Display Properties control panel: Area Note Click Start, point to Settings and click Control Panel.
  • Page 73 Advanced Controls Figure 3 - 3 Advanced Display Properties ATI Mobility Radeon 9700 Series Properties You can also access ATI Mobility Radeon Properties right- clicking the ATI icon in the taskbar. Point to Settings and Open the Display Properties control panel, and click the Advanced (but- click ATI Display Set- ton) to bring up the ATI Mobility Radeon 9700 Series...
  • Page 74 Advanced Controls Figure 3 - 4 ATI Mobility Radeon 9700 Properties Tabs Help Menus Right-click on almost any item in the tabs to bring up the “What’s This?” button. Click to Configure Theater Mode Help Menu Click “What’s (Not Supported with TV Tuner) This?”...
  • Page 75 Advanced Controls Access the menus from ATI taskbar to get further help on display options, TV options etc. Right-click the ATI icon in the taskbar and point to Help or Troubleshooting (Figure 3 - 5). You can also switch between the displays and go to the ATI Mobility Radeon 9700 Series...

  • Page 76: Display Devices

    Advanced Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel dis- play or TV/HDTV as your display device. The following are the display op- Drivers tions: You are unable to use most advanced con- The built-in LCD.

  • Page 77: Display Options

    Advanced Controls Display Options Table 3 - 1 Display Options Display Mode Windows XP Windows 2000 Single Theater Mode Multiple - Clone Mode Theater Mode can be Multiple - Extended enabled clicking Not Available Desktop Mode Clone Mode Options (button) in the Overlay Single - Either the LCD, Monitor, Flat Panel Display or TV as a display device.

  • Page 78: Attaching A Monitor

    Advanced Controls Attaching a Monitor If you prefer to use a monitor or Flat Panel Display, connect it to the DVI-Out port on the rear panel (see “Rear View” on page 1 - 17). You may need to use Function Key a DVI to VGA converter.

  • Page 79: Enabling Other Displays

    Advanced Controls Enabling Other Displays Other displays are enabled from Display in the ATI Mobility Radeon 9700 Series... Properties Window (Figure 3 - Primary & Clone Displays Attach your external monitor to the DVI-Out port (or TV/HDTV to the S- The Primary display in Video Out port), and turn it on.

  • Page 80: Clone Mode

    Advanced Controls Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same con- Display Data Channel tent. Use this feature to display the screen through a projector for a presenta- Information tion.

  • Page 81: Extended Desktop Mode

    Advanced Controls Extended Desktop Mode The system supports Extended Desktop (the LCD and a CRT showing differ- ent views) in multiple display environments in WindowsXP, but this mode is NOT supported in Windows2000 . An Extended Desktop creates a desktop spanning multiple displays and acts as a large workspace.
  • Page 82 Advanced Controls 11. In the example shown in Figure 3 - 9 the primary monitor is on the left, the other display is on the right. Help Click either the Display Further help is avail- pop-up menu, or click able through the icon for the appro- menus accessed from...
  • Page 83 Advanced Controls 13. One display will be set to 1 (Primary), and the other to 2 (Clone). The displays may be switched as long as one as set to Primary. Figure 3 - 10 Displays Tab (Extended Desktop Mode) 14. To switch from Extended Desktop mode back to Clone mode, first uncheck the tick box to disable the Extended Desktop (via the settings tab in the Display Properties control panel) and click Apply (see “Extended...

  • Page 84: Enabling Tv Display

    Advanced Controls Enabling TV Display To display desktop images on a TV display, connect the TV to your computer by using an S-Video cable from the TV to the S-Video Out Port at the rear of TV Format the computer (see “Rear View”...

  • Page 85: High Definition Tv Display

    Advanced Controls High Definition TV Display To display desktop images on an HDTV display, connect the HDTV to your computer by using a HDTV converter (S-Video to YPrPb) connected to the S- HDTV Display Tab Video Out Port at the rear of the computer (see “Rear View”...

  • Page 86: Power Management Features

    Advanced Controls Power Management Features To conserve power, especially when using the battery, your notebook comput- er has two types of power management available, ACPI and APM. Power OS Note management conserves power by controlling individual components of the Power management computer (the monitor and hard disk drive) or the whole system.

  • Page 87: Enabling Power Options

    Advanced Controls Enabling Power Options Power Options are enabled through the Control Panel in your Windows sys- tem (Power Options). With other operating systems you may have power management available, so check your documentation. Figure 3 - 13 Power Options Control Panel You may conserve power through Power Schemes (individual components) or throughout the whole system.

  • Page 88: Power Schemes

    Advanced Controls Power Schemes You can set your computer to conserve power through individual components Power Schemes & by means of Power Schemes. Each scheme will also adjust the processor per- CPU Performance formance of your machine in order to save power (see sidebar). The settings Windows Power for each scheme can be adjusted to set the monitor to turn off after a specified...

  • Page 89: Conserving Power Throughout The System

    Advanced Controls Conserving Power Throughout the System With this function you can stop the notebook’s operation and restart where you left off. This system features Standby and Hibernate suspend mode lev- System Suspend els (Hibernate mode will need to be enabled by clicking the option in the Hi- Mode &...

  • Page 90: Standby

    Advanced Controls Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is System Resume made to idle at its slowest speed. All open applications are retained in memo- The system can re- ry.

  • Page 91: Configuring The Power Button

    Advanced Controls Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate modes (Figure 3 - 16). In Standby mode the LED will flash Suspend/Resume green, in Hibernate mode the LED will be off. If you are in a power saving Button mode set to save power through individual components (e.g.

  • Page 92: Battery Information

    Advanced Controls Battery Information Please follow these simple guidelines to get the best use out of your battery. Caution New Battery Danger of explosion if Always completely discharge, then fully charge, a new battery before using it battery is incorrectly (see “Battery FAQ”...

  • Page 93: Battery Faq

    Advanced Controls Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery We recommend that you do not remove the battery yourself. If you do need to Power remove the battery for any reason see “Battery Removal”...

  • Page 94: Configuring The Infrared Settings For Fir

    Advanced Controls Configuring the Infrared Settings for FIR To configure your computer for Fast Infrared (FIR) communication follow these steps: Infrared Communication Click Start, point to Settings and click Control Panel (or just click Start > The infrared transceiv- Control Panel). er operates on a “Line Double-click Wireless Link (Printers and Other Hardware Category) icon.

  • Page 95: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities Overview This chapter deals with installing the drivers and utilities essential to the operation or improvement Assumption of some of the computer’s subsystems. The system We assume that you will install all drivers and utili- takes advantage of some newer hardware compo- ties from the built-in CD device and it is assigned to nents for which the latest versions of most available...

  • Page 96: Windows Xp & 2000 Service Packs

    Drivers & Utilities Windows XP & 2000 Service Packs Check the warnings on this page regarding installa- tion of the appropriate Service Pack for your Win- dows XP OS (if you are unsure of the Service Pack Windows XP Service Pack 1/1a currently installed see below).

  • Page 97: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message If you receive a message telling you that the driver you are installing is not authorized (Digital Signa- ture Not Found), just click Yes or Continue Any- Navigate (Browse..) to D: way to ignore the message and continue the You will notice that many of the instructions for driv- installation procedure.

  • Page 98: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from the table Table 4 - 1 on page 4-6 (the drivers must be You have a choice of installation methods to install installed in this order) which is the same as your drivers.

  • Page 99: Driver Install

    Drivers & Utilities Driver Install Insert the Device Drivers & Utilities + User’s Manual CD-ROM and select the appropriate driver from the menu on the left, then click Driver Install (button) and follow the procedures listed in this chapter. Manual Install To use the manual install method insert the Device Drivers &...
  • Page 100 Drivers & Utilities Table 4 - 1 - Installation Order Feature Windows 2000 Win XP RAID “RAID Configuration” on page 7 - 17 Chipset page 4 - 7 page 4 - 12 Audio page 4 - 8 page 4 - 13 Modem page 4 - 8 page 4 - 13...

  • Page 101: Windows 2000 Professional

    Drivers & Utilities Windows 2000 Professional This section covers driver and utility installation in- structions for Windows 2000 Professional with Ser- vice Pack 4 included. Windows 2000 with Service Pack 4 New Hardware Found Make sure that your Windows 2000 version in- If you see the message “New Hardware Found”...

  • Page 102: Audio (Win2000)

    Drivers & Utilities Audio (Win2000) Modem (Win2000) 1. Insert the Device Drivers & Utilities + User’s 1. Insert the Device Drivers & Utilities + User’s Manual CD-ROM or click Start (menu) > Manual CD-ROM or click Start (menu) > Run ... and navigate (Browse..) to Run ...

  • Page 103: Lan (Win2000)

    Drivers & Utilities LAN (Win2000) Hot-Key (Win2000) 1. Insert the Device Drivers & Utilities + User’s The Silent Install option is not available for the Manual CD-ROM or click Start (menu) > Hot-Key driver. Run ... and navigate (Browse..) to D:\SETUP.EXE and click OK.

  • Page 104: Touchpad (Win2000)

    Drivers & Utilities TouchPad (Win2000) AutoMail (Win2000) 1. Insert the Device Drivers & Utilities + User’s The Silent Install option is not available for the Manual CD-ROM or click Start (menu) > Hot-Key driver. Run ... and navigate (Browse..) to D:\SETUP.EXE and click OK.

  • Page 105: Windows Xp

    Drivers & Utilities Windows XP This section covers driver and utility installation in- structions for Windows XP. Windows XP Service Pack 1/1a New Hardware Found Make sure you install Windows XP Service Pack 1/ 1a (or are installing a Windows XP version which in- If you see the message “New Hardware Found”...

  • Page 106: Chipset (Winxp)

    Drivers & Utilities Chipset (WinXP) 1. Insert the Device Drivers & Utilities + User’s Manual CD-ROM or click Start (menu) > Run ... and navigate (Browse..) to Enabling USB 2.0 Support D:\SETUP.EXE and click OK. 1.If you can see the My Computer icon on your 2.

  • Page 107: Audio (Winxp)

    Drivers & Utilities Audio (WinXP) Modem (WinXP) 1. Insert the Device Drivers & Utilities + User’s 1. Insert the Device Drivers & Utilities + User’s Manual CD-ROM or click Start (menu) > Manual CD-ROM or click Start (menu) > Run ... and navigate (Browse..) to Run ...

  • Page 108: Lan (Winxp)

    Drivers & Utilities LAN (WinXP) Hot-Key (WinXP) 1. Insert the Device Drivers & Utilities + User’s The Silent Install option is not available for the Manual CD-ROM or click Start (menu) > Hot-Key driver. Run ... and navigate (Browse..) to D:\SETUP.EXE and click OK.

  • Page 109: Touchpad (Winxp)

    Drivers & Utilities TouchPad (WinXP) AutoMail (WinXP) 1. Insert the Device Drivers & Utilities + User’s The Silent Install option is not available for the Manual CD-ROM or click Start (menu) > Hot-Key driver. Run ... and navigate (Browse..) to D:\SETUP.EXE and click OK.
  • Page 110 Drivers & Utilities 4 - 16...

  • Page 111: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return Configuration: The Setup utility Setup and restore the If your computer has never been set up, or you are making important changes Setup Defaults with...

  • Page 112: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- POST Screen duct a POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. 2.CPU type If there is a problem that prevents the system from booting, it will display a 3.Memory status...

  • Page 113: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 114: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- Setup Screens age basic features and subsystems (e.g. port configuration). Instructions on how to Entering Setup navigate each screen are in the box at the To enter Setup, turn on the computer and press F2 during the POST.

  • Page 115: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 PhoenixBIOS Setup Utility Main Menu Main Main Advanced Security Boot Exit Item Specific Help System Time: [16:11:05] System Date: [01/20/2004] <Tab>, <Shift Tab>, or IDE Channel 0 Master [CD-ROM] <Enter> selects field. IDE Channel 1 Master [None] CPU Type:...
  • Page 116 BIOS Utilities IDE Channel * Master (Main Menu) Pressing Enter under opens the sub-menu to show the configuration of the Primary Master device e.g. the CD drive and hard disk. These items are con- Switching Hard Disks figured automatically for you. Every time you install a CPU Type, L2 Cache Size, FSB Frequency, DRAM Frequency (Main different hard disk in...

  • Page 117: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Boot Exit Item Specific Help Setup Warning Setting itmes on this menu to incorrect values may cause your system to malfunction. Select 'Yes' if you want to clear the Reset Configuration Data [WNo]...
  • Page 118 BIOS Utilities I/O Device Configuration (Advanced Menu) The sub-menus under this item include options to configure the Serial port A (Serial Mouse) and Parallel (Printer) port. These can be left to the default settings, however you may wish to use certain devices that require settings to be adjusted accordingly.
  • Page 119 BIOS Utilities CPU Clock Adjust: (Advanced Menu) If you choose “Enabled” the CPU clock will save power if you are not using the AC adapter in order to increase the battery life. Battery Low Beep Warning (Advanced Menu) Use this menu to enable/disable the warning beep sound when the battery reaches a low power level.
  • Page 120 BIOS Utilities USB Device 29, Function 1&2&3 This option allows you to enable/disable support for all USB ports, except the lower rear port. This is “Enabled” by default, however if you are installing an Operating System Operating System see the sidebar. If you set this option to “Disabled” to install Installation Warning the operating system (you will need to use an external floppy drive attached If you are installing an...

  • Page 121: Security Menu

    BIOS Utilities Security Menu Figure 5 - 4 PhoenixBIOS Setup Utility Security Menu Main Advanced Security Security Boot Exit Item Specific Help Supervisor Password Is: Clear User Password Is: Clear Supervisor Password Set Supervisor Password [E E nter] controls access to the Set User Password: [Enter] setup utility.

  • Page 122: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 5 PhoenixBIOS Setup Utility Boot Menu Main Advanced Security Boot Exit Boot Item Specific Help +Removable Devices Keys used to view or CD-ROM Drive configure devices: +Hard Drive <Enter> expands or collapses devices with Network Boot a + or - <Ctrl+Enter>...
  • Page 123 BIOS Utilities Boot devices usually are hard drives, floppy drives, CD-ROMs and LANs (Local Area Networks). When you specify a device as a boot device on the Boot Menu, it requires the availability of an operating system on that device. Most home computers come with an operating system already installed on “Drive C:”.

  • Page 124: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help Select Item...

  • Page 125: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains the information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or prob- lems you can contact your service representative for further help. Before you begin you will need: •...

  • Page 126: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • your system is still under warranty or a service contract dures, make sure that •...

  • Page 127: Battery Removal

    Upgrading The Computer Battery Removal When upgrading your computer it is recommended that you remove the bat- tery for safety purposes. If you have the 12 cell battery option, there will be Bay Three Device no device in Bay Three. The battery removal pictured includes a sub Shut the computer down, place it on a clean, stable surface and turn it over.

  • Page 128: Upgrading The Cd/Dvd Device (Bay Two)

    Upgrading The Computer Upgrading the CD/DVD Device (Bay Two) Shut the computer down and remove the battery (see “Battery Removal” on page 6 - Remove screws Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can either disconnect it or leave it attached).

  • Page 129: Upgrading The Hard Disk(S)

    Upgrading The Computer Upgrading the Hard Disk(s) The hard disk drive(s) is (are) used to store your data internally in the comput- er. The hard disk drive) is mounted in a removable case, and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5 mm. Jumper Settings for Multiple Hard Disk Use If you are using more than one hard disk in your computer, make sure to set the jumpers on all your hard disks to the cable select option in order for the system to...
  • Page 130 Upgrading The Computer Shut the computer down and remove the battery (see “Battery Removal” on page 6 - Remove screws from the HDD cover, and the cover Remove screws from the primary hard disk assembly (or secondary hard disk assembly). Figure 6 - 3 Removing the HDD Assembly...
  • Page 131 Upgrading The Computer Take the HDD assembly out of the case, and remove the screws and separate the HDD connector cable , and case Just reverse the removal procedure to install the new HDD assembly. Figure 6 - 4 Separating the HDD, Cable &...

  • Page 132: Some Things To Watch Out For

    Upgrading The Computer Some Things to Watch Out For Software Allow the system to auto-detect the new HDD, or if necessary, run the Setup HDD System Warning Utility in the BIOS to customize the system. New HDDs are blank. Setting Up a New HDD Before you begin make Follow your operating system’s installation instructions and install all neces- sure:...

  • Page 133: Upgrading The System Memory

    Upgrading The Computer Upgrading the System Memory The computer has two 64-bit wide DDR data channels memory for 200-PIN 400MHz or 333MHz DDR Small Outline Dual In-line Memory Modules (SO- DIMM). The main memory can be expanded up to 2GB, and accepts 128/256/ 512/1024 MB modules.
  • Page 134 Upgrading The Computer Figure 6 - 6 Removing the Memory Module(s) If there is a module currently installed which needs to be upgraded/replaced then remove it by gently pulling latches on the memory socket as indicated in Figure 6 - The module will pop-up, and you can remove it.

  • Page 135: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a faster/new one you will need to contact your customer service representa- Warranty tive. We recommend that you do not do this yourself, since if it is done incor- The CPU is not a user rectly you may damage the processor or mainboard.
  • Page 136 Upgrading The Computer 6 - 12...

  • Page 137: Options

    Options Chapter 7: Options Overview This chapter contains the information on the various optional items which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...

  • Page 138: The 7-In-1 Card Reader

    Options The 7-In-1 Card Reader The card reader allows you to use the most popular digital storage cards. The formats which can be read include: • MMC (MultiMedia Card) • SD (Secure Digital) • MS (Memory Stick) • MS (Memory Stick Pro) •...

  • Page 139: Tv Tuner

    Options TV Tuner The optional TV Tuner allows you to watch TV, play music CDs, video con- ference and capture still images and video on your PC. TV Tuner Remote The TV Tuner comes with a remote control unit, a CD with TV Studio Appli- The remote control unit provided with the op- cation Utility Software (containing a User Guide) and a quick driver installa-...

  • Page 140: The Wireless Lan & Bluetooth Modules

    Options The Wireless LAN & Bluetooth Modules If your purchase option includes the 802.11g Wireless LAN module and/or Wireless Device Bluetooth module, follow the information on the following pages for instruc- Operation Aboard tions on installing the driver. Pay careful attention to the warnings concerning Aircraft the use of wireless modules aboard aircraft, and the instructions on enabling/ The use of any porta-...

  • Page 141: The Wireless Lan Module

    Options The Wireless LAN Module Wireless LAN Driver Installation (Win2000) 1. Make sure the WLAN module is powered ON (see page 2. Insert the Wireless LAN CD-ROM into the CD drive. 3. The program will run automatically. 4. Click Install Software (button). 5.

  • Page 142: Wireless Lan Driver Installation (Winxp)

    Options Wireless LAN Driver Installation (WinXP) 1. Make sure the WLAN module is powered ON (see page 2. Insert the Wireless LAN CD-ROM into the CD drive. 3. The program will run automatically. 4. Click Install Software (button). 5. Click Next. 6.
  • Page 143 Options Figure 7 - 3 Wireless LAN Screens (WinXP) The Wireless LAN Module 7 - 7...

  • Page 144: The Bluetooth Module

    Options The Bluetooth Module Bluetooth Driver Installation (Win2000) 1. Make sure the Bluetooth module is powered ON (see page 2. Click cancel if you see the “New Hardware Found” message. 3. Insert the Bluetooth CD-ROM into the CD drive. 4. The program will run automatically. 5.

  • Page 145: Bluetooth Driver Installation (Winxp)

    Options Bluetooth Driver Installation (WinXP) 1. Make sure the Bluetooth module is powered ON (see page 2. Click cancel if you see the “New Hardware Found” message. 3. Insert the Bluetooth CD-ROM into the CD drive. 4. The program will run automatically. 5.
  • Page 146 Options Figure 7 - 4 Bluetooth Control Panel & My Bluetooth Places 7 - 10 The Bluetooth Module...

  • Page 147: Pc Camera

    Options PC Camera If you have purchased the optional PC Camera you will need to install the de- vice driver for it as indicated in the following pages (only install the drivers for the optional modules you have purchased). After installing the driver you can run the application software by going to the PC Camera 301P item in the Start >...

  • Page 148: Pc Camera Driver Installation (Win2000/Xp)

    Options PC Camera Driver Installation (Win2000/XP) 1. Insert the PC Camera CD-ROM into the CD Drive. 2. Click Start (menu) > Run ... 3. Navigate (Browse...) to D:\Default setting_60Hz\SETUP.exe and click 4. Click Next > Finish to restart the computer. 5.

  • Page 149: Audio Setup

    Options Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. To do this in Windows XP (for Win- Windows 2000 Audio dows 2000 see sidebar): Setup Go to the Start menu and point to Settings and click Control Panel, then Go to the Start menu...
  • Page 150 Options Windows 2000 Audio Setup (continued) Make sure the Select (check box) in the Mi- crophone section is checked, and boost the volume as high as it will go. Close the windows. Figure 7 - 5 Audio Setup (Windows XP) 7 - 14 PC Camera...

  • Page 151: Amcap

    Options AMCAP AMCAP is a video viewer useful for general purpose video viewing and test- ing, and can capture video files to .avi format. Pre-Allocating File To capture video: Space Run the AMCAP program from the Start > Programs menu (it is recom- You may pre-allocate mended that you set the capture file before the capture process - see Set the file size for the cap-...
  • Page 152 Options Eliminating Screen Flicker If you find that the video screen in the AMCAP program is flickering, you can try to adjust the option from the Video Capture Filter options. Run the AMCAP program from the Start > Programs menu. Go to Options and scroll down to select “Video Capture Filter...”.

  • Page 153: Raid Configuration

    Options RAID Configuration If you have included the optional RAID (Redundant Array of Independent Disks) configuration in your purchase option, this will allow you to use your hard disks in combination with Striping (RAID 0) or Mirroring (RAID 1) for fault tolerance and performance. RAID Level Description Identical drives reading and writing data in parallel to increase...

  • Page 154: Jumper Setting For Raid/Ata Configuration

    Options Jumper Setting for RAID/ATA Configuration Follow the procedure to remove the secondary hard disk (see “Upgrading the Hard Disk(s)” on page 6 - Locate the jumper at point Use a bent paper clip to push the switches up to ON for RAID mode, or down to off for ATA mode.

  • Page 155: Raid Setup

    Options RAID Setup To create a disk array you will need to open the FastBuild Utility which is built into the BIOS if you have included the RAID option in your purchase config- uration. You will also need a blank floppy disk, and external USB floppy disk drive.
  • Page 156 Options Startup the computer, and when you see the screen below press the Ctrl + F key combination to enter the utility. Figure 7 - 8 FastTrak 100 "Lite" (tm) BIOS Version 2.02.1.5 (C) 2002-2005 Promise Technology, Inc. All rights reserved. FastTrak BIOS Screen Examples No Array is defined ......
  • Page 157 Options You can create two types of array as outlined in Table 7 - 1, “RAID Descrip- tion,” on page 7 - • RAID 0 - A Striped array for enhanced performance (1 or 2 drives) Setup Options • RAID 1 - A Mirrored array for data security (2 drives treated as one) What options are avail- able in “Optimize Ar- After the FastBuild Utility you will see the menu options below:...
  • Page 158 Options You will now need to format the array as if it were a single hard drive. Have a floppy disk ready and copy the RAID\Drivers folder from the Device Drivers & Utilities + User’s Manual CD-ROM (Navigate/Browse.. to D:Drivers\RAID\Drivers) to the floppy disk. Startup from your operating system CD (Windows XP or Windows 2000 including Service Pack 4).

  • Page 159: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting the service center, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the an- swer in these pages, make sure you have followed the instructions carefully and observed the safety pre- cautions in the preface.

  • Page 160: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 161: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases e.g.

  • Page 162: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 163: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 164 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 165: Power

    Troubleshooting Power Problem Possible Cause/Solution You turned on the power The battery is missing or incorrectly installed - Make sure the battery is present and seated but it doesn’t work. properly in the battery bay, and that nothing is interfering with the battery contacts. (The battery status LED , doesn’t light up.) The battery status LED...
  • Page 166 Troubleshooting Problem Possible Cause/Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked hot. (see “Overheating” on page 1 - 17). If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour.

  • Page 167: Display

    Troubleshooting Display Problem Possible Cause/Solution Nothing appears on The system is in a power saving mode - Toggle the suspend key combination Fn + F4 screen. (see “The Function Keys and Numeric Keypad” on page 2 - 20). The screen controls need to be adjusted - Toggle the screen control key combinations Fn + F8 and F9 (see “Opening the LCD”...

  • Page 168: Boot Password

    Troubleshooting Boot Password Problem Possible Cause/Solution You forget the boot If you choose to set a boot password, NEVER forget your password. The consequences of password. this could be serious. If you cannot remember your boot password you must contact your service representative and you may lose all of the information on your hard disk.

  • Page 169: Audio

    Troubleshooting Audio Problem Possible Cause/Solution The sound cannot be The volume might be set too low. Click the Speaker icon on the taskbar to check the heard or the volume is setting. Check the volume control in the Sound Control Panel in the Windows Toolbar. very low.

  • Page 170: Cd Device

    Troubleshooting CD Device Problem Possible Cause/Solution The compact disc cannot The compact disc is dirty - Clean it with a CD-ROM cleaner kit. be read. The compact disc tray The compact disc is not correctly placed in the tray - Gently try to remove the disc using will not open when there the eject hole (see “Loading Compact Discs”...

  • Page 171: Keyboard And Mouse

    Troubleshooting Keyboard and Mouse Problem Possible Solution Unwelcome numbers The NumLk is turned ON (the LED is lit) - Press and release the Fn & NumLk keys. appear when typing. Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.

  • Page 172: Operation

    Troubleshooting Operation Problem Possible Solution The system freezes or The system’s power saving features have timed-out (the screen goes dark). Use the AC the screen goes dark. adapter, press the Fn + F4 (Suspend) key combination, or press the Power Button if no LEDs are lit.

  • Page 173: Appendix A. Specifications

    Appendix A. Specifications Feature Specification µ Processor Types Intel Pentium® Processor (478-pin) Micro- 0.13) 0.13 Micron Process Technology, µ )FCPGA Package 512K On-Die L2 Cache & 800MHz Front Side Bus - 2.4/ 2.6/ 2.8/ 3.0/ 3.2 GHz µ Intel Prescott Processor (478-pin) Micro- 0.09) 0.09 Micron Process Technology, µ...
  • Page 174 Feature Specification Display ATI Mobility Radeon 9700 High Perfomance Chip Integrated 128-bit 2D/3D Graphics Accelerator Advanced HW Acceleration for DVD Playback Fully DirectX® 9 Support Ultra AGP™ 8x 256MB DDR SGRAM On Board Dual-View Display Monitor External Display Resolution up to 1600 * 1200 HDTV Support Storage One Changeable Optical Device (DVD-ROM/ Combo/ CD-RW/ DVD+RW/ DVD-RW /DVD-Dual...
  • Page 175 Feature Specification Keyboard, Full Size Winkey Keyboard with Numeric Built-In TouchPad Pointing Device & Keypad 3 Hot Keys (Default Internet Browser/ Default Buttons Email Program & Application) Interface & Three USB 2.0 Ports One S/PDIF Out Port Communication One Mini IEEE1394 Ports One RJ-11 Jack (Modem) One S-Video Jack for TV Output One RJ-45 Jack (Local Area Network)
  • Page 176 Feature Specification Power Supports ACPI v1.0b Supports Battery Low Sleep Management Supports Hibernate/Standby Modes Supports Resume From Modem Ring Power Full Range AC Adapter - AC-In 100~240V, 50~60Hz, DC Output 20V, 7.5A Easy Changeable Main Battery Smart Li-Ion Environmental Temperature Relative Humidity °...

Table of Contents
