Disassembly

Removing the Processor

1. Turn off the computer and remove the battery
2. Remove screws
3. Carefully lift up the memory socket cover
Figure 9
disconnect it or leave it attached).
4. Remove screws
Processor Removal
5. Carefully lift up the heat sink
a. Remove the screws.
b. Carefully lift the cover off
the computer.
a.
c. Remove the screws in
the order indicated.
d. Remove the heat sink.
Heat Sink Unit
The elongated heat
sink 15 pictured ap-
plies to models in this
series with two CPU
fan units. Some mod-
els may have a shorter
c.
heat sink unit and a
single CPU fan.
9. Socket Cover
15. Heat Sink
• 10 Screws
2 - 16 Removing the Processor
- from the memory socket cover
1 7
- from the heat sink, in the order indicated on the label
11 14
off the computer.
15
8 7
1 2 6
3
4
5
13
12
(page 2 - 8).
.
(a fan cable is still attached to the mainboard and you can either
9 10
10
b.
9
d.
15
14
11
.
Reassembly Screw
Order
When replacing the
heat sink, make sure
you insert the screws
in the same order indi-
cated on the label.
