Disassembly

Removing the Modem

1. Turn off the computer and remove the battery
(page 2 -
and center cover
2. Remove screws
3. Lift up the modem module
Figure 17
Modem Removal
a. Remove the screws and
release the cable.
b. Lift the modem module
and cable off the compu-
ter.
4. Modem Module
• 2 Screws
2 - 24 Removing the Modem
12), Bluetooth module (page 2 -
(page 2 - 18), LCD assembly
& , and release the modem cable at point
1 2
and cable.
4
a.
3
11
2
1
(page 2 - 8), HDD (page 2 - 9), memory
14), WLAN module (page 2 - 15), processor
(page 2 - 19), and top case module
.
3
b.
4
(page 2 - 10), CD device
(page 2 - 16), keyboard
(page 2 - 21).
