Removing the Wireless LAN Module

1. Turn off the computer and remove the battery
2. Remove screws - from the memory socket cover
1 8
3. Carefully lift up the memory socket cover
disconnect it or leave it attached).
4. Remove screws & , and carefully disconnect cables
11 12
5. Lift the Wireless LAN module
8 7
a.
1 2
3
c.
13
11 12
14
(page 2 - 8).
.
(a fan cable is still attached to the mainboard and you can either
9 10
&
13
off the computer.
15
b.
6
4
5
d.
.
14
10
9
15
Removing the Wireless LAN Module 2 - 15
Disassembly
Figure 8
Wireless LAN
Module Removal
a. Remove the screws.
b. Carefully lift the cover off
the computer.
c. Remove the screws and
disconnect the cables.
d. Remove the WLAN
module.
Antenna Cable
Connection
When re-inserting a
Wireless LAN module,
make sure the antenna
cable connects to the
connector J1 which is
indicated at point 14.
9. Socket Cover
15. WLAN Module
.
• 10 Screws
