Summary of Contents for EUROCOM D900T PHANTOM

  • Page 3: Trademarks

    Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be dam- aged.
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifi- Warning cations, consult your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Preface Contents Notice ................I System Map: Left View ......... 1-10 Trademarks ............I System Map: Right View ........1-11 System Map: Bottom View ........1-12 FCC Statement ...........II Windows XP Start Menu & Control Panel .... 1-13 Instructions for Care and Operation ....IV Video Features ............
  • Page 16 Preface Configuring the Infrared Settings for FIR ....2-13 The Power Sources ..........4-2 Adding a Printer .............2-14 AC Adapter ............4-2 USB Printer ............2-14 Battery ..............4-2 Install Instructions: ..........2-14 Turning on the Computer ......... 4-3 Parallel Printer ............2-14 Power Schemes ............4-4 System Power Options ..........
  • Page 17 Preface Driver Installation ............5-6 Entering Setup ............6-4 Manual Driver Installation ........5-7 Setup Screens ............6-5 Windows XP & 2000 Professional ......5-8 Main Menu ............... 6-6 New Hardware Found ..........5-8 System Time & Date (Main Menu) ......6-6 Chipset (WinXP & 2000) ........5-9 IDE 0/1 (Main Menu) ..........
  • Page 18 Preface Upgrading the System Memory (RAM) ....7-7 RAID Configuration ..........8-16 Upgrading the Optical (CD/DVD) Device(s) ...7-9 RAID Setup ............8-18 Upgrading the Processor ........7-10 Troubleshooting Modules Overview ..............9-1 Overview ..............8-1 Basic Hints and Tips ..........9-2 The Wireless LAN & Bluetooth Modules ....8-2 Backup and General Maintenance ......
  • Page 19 Preface RJ-45 LAN Jack ............A-3 Communication ............B-4 CATV-In Jack ............A-3 Card Reader .............B-4 S-Video-In Jack ............A-3 Indicators ..............B-5 S-Video-Out Jack ............A-3 Power Management ..........B-5 USB 2.0/1.1 Ports ............A-3 Power ...............B-5 Mini-IEEE 1394a Ports ...........A-4 Environmental Spec ..........B-5 Line-In Jack .............A-4 Physical Dimensions &...
  • Page 20 Preface XVIII...

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 5 - “BIOS Utilities” on page 6 - 1 “Upgrading The Computer”...

  • Page 23: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the following oper- ating systems: •...

  • Page 24: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC adapter.

  • Page 25: System Map: Top View With Lcd Panel Open

    Quick Start Guide System Map: Top View with LCD Panel Open Optional Built-In PC Camera Wireless Device Oper- ation Aboard Aircraft LED Power & Communication The use of any portable Indicators electronic transmission Speakers devices aboard aircraft LED Status Indicators usually prohibited.

  • Page 26: Led Indicators

    Quick Start Guide LED Indicators Table 1 - 2 - LED Power & Communication Indicators The two sets of LED indicators (LED Status Indica- Icon Color Description tors and LED Power & Communication Indicators) on the computer display helpful information about the Orange DC Power is Plugged In current status of the computer.

  • Page 27: Hot-Key Buttons

    Quick Start Guide Hot-Key Buttons Function Keys & Numeric Keypad These keys access the internet, e-mail or a user-de- The keyboard has an embedded numerical keypad for fined application with one quick button press. Make easy numeric data input (see Figure 1 - sure you install the driver to enable the Hot-Key func- tions (refer to...
  • Page 28 Quick Start Guide Table 1 - 4 - Function Keys Figure 1 - 3 - Keyboard Keys Description Function Key Fn + F3 Mute Toggle Function Keys Fn + F4 Sleep Toggle Num Lk & Scr Lk Keys Fn + F5 Decrease Audio Volume Fn + F6 Increase Audio Volume...

  • Page 29: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front & Rear Views LCD Latches Audio DJ Player Controls Consumer Infrared Transceiver Audio DJ Player Vent/Fan Intake DC-In Jack The built-in standalone audio CD player gives you direct hardware control for audio CDs (MP3 compatible) when the computer is shut down, but has a working power source.

  • Page 30: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 5 Left View S-Video-Out Jack 4 * USB 2.0 Ports 2 * Mini-IEEE 1394a Port Line-In Jack S/PDIF-Out Jack Microphone-In Jack Mini-IEEE 1394a Headphone-Out Jack Both Mini-IEEE 1394a ports only support SELF POWERED IEEE 1394a devices. 7-in-1 Card Reader PC Card Slot 7-in-1 Card Reader Formats...

  • Page 31: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 6 - Right View Primary Optical Device Drive Bay (for CD/DVD Device) Secondary Optical Device Drive Bay (for CD/DVD Device) Security Lock Slot Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives.

  • Page 32: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 7 - Bottom View Battery Vent/Fan Intake Memory (RAM) Cover The CPU is not a user Hard Disk Cover serviceable part. Sub Woofer Opening this compart- ment, or accessing the CPU in any way, may violate your warranty.

  • Page 33: Windows Xp Start Menu & Control Panel

    Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 34: Video Features

    Quick Start Guide Video Features Video Driver Controls You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the video driver is installed. For further video information see “Video & Audio Controls” on page 3 - Click Start, point to Settings and click Control Panel (or just click Control Panel).

  • Page 35: Display Devices & Options

    Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the DVI-Out port, a TV to the S- Video-Out jack.You have the following display modes available from nView Display Settings (tab) in the Ge- Force 6800 Go Properties control panel tab (see Chapter 3“Video &...

  • Page 36: Power Management Features

    Quick Start Guide Power Management Features The Power Options control panel in Windows (see page 12) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Standby or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel as pictured in Figure 1 - 10).

  • Page 37: Storage Devices, Mail Program, Mouse & Printer

    Storage Devices, Mail Program, Mouse & Printer Chapter 2: Storage Devices, Mail Program, Mouse & Printer Overview Read this chapter to learn more about the following main features and compo- nents of the computer: • The Hard Disk Drive • The Optical (CD/DVD) Device •...

  • Page 38: Hard Disk Drive

    Storage Devices, Mail Program, Mouse & Printer Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk Power Safety can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5 mm.

  • Page 39: Optical Device

    Storage Devices, Mail Program, Mouse & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The ac- Sound Volume tual device will depend on the model you purchased (see “Storage Options” Adjustment on page B - 3).

  • Page 40: Handling Cds Or Dvds

    Storage Devices, Mail Program, Mouse & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/ CD Emergency Eject DVDs can be accessed.

  • Page 41: Dvd Regional Codes

    Storage Devices, Mail Program, Mouse & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Geographical Location Region DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 42: 7-In-1 Card Reader

    Storage Devices, Mail Program, Mouse & Printer 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push Operating System the card into the slot and it will appear as a removable device. Installation Warning •...

  • Page 43: Pc Card Slot

    Storage Devices, Mail Program, Mouse & Printer PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC Card. Make sure you install the driver for the PC Card (see “What to Install” on page 5 - Inserting and Removing PC Cards •...

  • Page 44: Check Mail Program

    Storage Devices, Mail Program, Mouse & Printer Check Mail Program After you have installed the driver for the Check Mail program (see “What to Install” on page 5 - 1) you may then configure it to give notification when new mail is received. You must be online to receive this notification (note that this program only supports the POP3 protocol), and your default mail program does not need to be open.
  • Page 45 Storage Devices, Mail Program, Mouse & Printer Clicking on Check Mail will bring up the following options menu. Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages. Figure 2 - 7 You may then configure the options for your mail server, user name, and Check Mail...
  • Page 46 Storage Devices, Mail Program, Mouse & Printer Figure 2 - 8 Check Mail Enabled You may enable an audible warning for received mail by clicking on Set Mail Wave, and browsing to a .WAV sound file to use for mail notifica- tion.

  • Page 47: Touchpad And Buttons/Mouse

    Storage Devices, Mail Program, Mouse & Printer TouchPad and Buttons/Mouse The TouchPad is a device for pointing (controlling input positioning) on the computer’s display screen by sensing finger movement, and downward pres- Mouse Driver sure. It is an alternative to the mouse; however, you can also add a mouse to If you are using an ex- your computer through one of the USB ports.

  • Page 48: Configuring The Touchpad And Buttons

    Storage Devices, Mail Program, Mouse & Printer Configuring the TouchPad and Buttons Once you have installed the TouchPad drivers (see “What to Install” on page 5 - 1) you can configure the functions by double-clicking the TouchPad driver icon on the taskbar. You may then configure the TouchPad tapping, buttons, scrolling, pointer motion and sensitivity options to your preferences.

  • Page 49: Configuring The Infrared Settings For Fir

    Storage Devices, Mail Program, Mouse & Printer Configuring the Infrared Settings for FIR To configure your computer for Fast Infrared (FIR) communication follow these steps: Infrared Communication Click Start, point to Settings and click Control Panel (or just click Start > The infrared transceiv- Control Panel).

  • Page 50: Adding A Printer

    Storage Devices, Mail Program, Mouse & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions Parallel Printer will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options.

  • Page 51: Video & Audio Controls

    Video & Audio Controls Chapter 3: Video & Audio Controls Overview This chapter covers: • Keyboard Video Controls • NVIDIA Video Driver Controls • Display Devices • Attaching Other Displays Drivers • Enabling TV Display You are unable to use •...

  • Page 52: Keyboard Video Controls

    Video & Audio Controls Keyboard Video Controls This section is about making adjustments for the LCD, and switching display Function Key devices. If you have any other display devices attached you can switch Combination through the display options with the Fn + Display (F7) toggle. You can use the FN + F7 key combination to Opening the LCD...

  • Page 53: Nvidia Video Driver Controls

    Video & Audio Controls NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” NVIDIA Taskbar Icon on page 1 - Click the NVIDIA icon NVIDIA GeForce 6800 Go Properties in the taskbar to bring up the trouble- More advanced video configuration options are provided in the GeForce 6800 shooting menu, and go...

  • Page 54: Additional Properties

    Video & Audio Controls Additional Properties The items listed in the Additional Properties window allow you to configure your display(s). If the items do not display you can either click the Additional Screenshots Properties button, or click the icon . All screenshots in this chapter are from the Windows XP OS.
  • Page 55 Video & Audio Controls You may make changes to the Display Settings, Color Correction, Video Overlay, Resolutions, Refresh Rates and Screen Rotation by clicking the ap- propriate tab and adjusting the setting. Figure 3 - 3 Screen Examples Right-click on a control panel item to bring up a Help menu Help Menus (see sidebar).

  • Page 56: Nvidia Nview Desktop Manager

    Video & Audio Controls NVIDIA nView Desktop Manager The nView Desktop Manager allows quick access to control panels for fea- tures such as Desktop Management, Profiles, Hot Keys etc. The Control panel Enable nView may be accessed as follows. Desktop Manger from Additional Click Start, point to Settings and click Control Panel (or just click Control Properties...

  • Page 57: Display Devices

    Video & Audio Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel dis- Display Wizard play or TV/HDTV as your display device. The following are the display op- tions: Use the Display Wiz- ard in the Desktop Management window The built-in LCD.

  • Page 58: Attaching Other Displays

    Video & Audio Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the DVI-Out Function Key Port at the rear of the computer. You can use the Fn + F7 key combination to Combination toggle through the display options.
  • Page 59 Video & Audio Controls Select the display option from the Primary Display/ Secondary Display dropbox. If you have a TV and external monitor/flat panel display attached you will have a number of available options (see sidebar). Select and Apply nView Display Mode the appropriate option.

  • Page 60: Display Modes

    Video & Audio Controls Display Modes Single Display Display Wizard Only one of your displays is used. Use the Display Wiz- Clone Mode ard in the Desktop Management window Clone Mode simply shows an exact copy of the Primary display desktop on to quickly setup and the other display(s).

  • Page 61: Enabling Tv Display

    Video & Audio Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an S-Video cable from the TV to the S-Video-Out jack on the left side of the computer (see “System Map: Left View”...
  • Page 62 Video & Audio Controls Set the TV format from the Select TV Format menu. The Advanced option (in Dualview mode) at the bottom of the Select TV Format menu allows you to select TV format by country if you are unsure of your TV format. Figure 3 - 8 TV Settings and Adjustments...

  • Page 63: Audio Features

    Video & Audio Controls Audio Features You can configure the audio options on your computer from the Sounds and Sound Volume Audio Devices /Sounds and Multimedia Windows control panel (see Adjustment Figure 1 - 8 on page 1 - 13), or from the Sound Effect Manager icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration How high the sound...

  • Page 64: Audio "Dj" Cd Player

    Video & Audio Controls Audio “DJ” CD Player The built-in standalone audio CD player gives you direct hardware control Disk Eject Warning for audio CDs/DVDs when the computer is shut down, but has a working power source. Don’t try to eject a CD/ DVD while the system 1.
  • Page 65 Video & Audio Controls TV Tuner Option If you have included the optional TV Tuner in your purchase con- figuration, you can use 1. Audio DJ Power Button the supplied remote 2. Previous Track control unit to control the audio “DJ”. 3.
  • Page 66 Video & Audio Controls 3 - 16...

  • Page 67: Power Management

    Power Management Chapter 4: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer uses the functions will vary ACPI power management system. Power management conserves power by slightly depending on controlling individual components of the computer (the monitor and hard disk your operating system.

  • Page 68: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC adapter or a battery pack. Power Button as Standby or Hibernate AC Adapter Button Use only the AC adapter that comes with your computer. The wrong type of If you are using a fully AC adapter will damage the computer and its components.

  • Page 69: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel. Shutdown Note that you should When the computer is on, you can use the power button as a Standby/Hiber- always shut your com- nate/Shutdown hot-key button when it is pressed for less than 4 seconds puter down by choos-...

  • Page 70: Power Schemes

    Power Management Power Schemes You can set your computer to conserve power through individual components Resuming Operation by means of Power Schemes. You can also adjust the settings for each scheme to set the monitor to turn off after a specified time, and the computer's The system can re- hard disk motor to turn off if the hard disk drive has not been accessed for a sume from Monitor or...
  • Page 71 Power Management Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 72: System Power Options

    Power Management System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - Figure 4 - 2 on page 4 -...

  • Page 73: Standby

    Power Management Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is System Resume made to idle at its slowest speed. All open applications are retained in memo- The system can resume ry.

  • Page 74: Configuring The Power Button

    Power Management Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate mode (Figure 4 - 3). In Standby mode, the LED will flash green. In Hibernate mode the LED will be off. If you are in a power saving mode set to save power through individual components (e.g.

  • Page 75: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning New Battery When the battery is Always completely discharge, then fully charge, a new battery (see “Battery critically low, immedi- FAQ”...

  • Page 76: Recharging The Battery With The Ac Adapter

    Power Management Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery”...

  • Page 77: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 78: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Caution Don’t turn off the computer by yourself even when you see a message that in- Danger of explosion if dicates the battery is critically low, just let the computer use up all of the bat- battery is incorrectly...

  • Page 79: Drivers & Utilities

    Drivers & Utilities Chapter 5: Drivers & Utilities What to Install This chapter deals with installing the drivers and utilities essential to the operation or improvement The Device Drivers & Utilities + User’s Manual of some of the computer’s subsystems. The system CD-ROM contains the drivers and utilities neces- takes advantage of some newer hardware compo- sary for the proper operation of the computer.
  • Page 80 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.

  • Page 81: Service Packs

    Drivers & Utilities Service Packs Check the warnings on the following pages regard- ing installation of the appropriate Service Pack for Windows 2000 with Service Pack 4 your Windows OS. If you are unsure of the Service Make sure that your Windows 2000 version in- Pack currently installed see below.
  • Page 82 Drivers & Utilities Windows XP Service Pack 1 Make sure you install Windows XP Service Pack 1(or a Windows XP version which includes Service Pack 1) before installing any drivers. Service Pack 1 includes support for USB 2.0. If you have upgraded the system by installing Service Pack 1 (i.e. your Windows XP version does not include Service Pack 1) then follow these instructions: 1.If you can see the My Computer icon on your desktop (if you cannot see the My Computer icon go to step 2) click on it once to select it, then right-click it to make the sub-menu appear and scroll down to Properties and...

  • Page 83: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Updating/Reinstalling Individual Drivers If you receive a message telling you that the driver you are installing is not authorized (Digital Signa- If you wish to update/reinstall individual drivers it ture Not Found), just click Yes or Continue Any- may be necessary to uninstall the original driver.To way to ignore the message and continue the do this go to the Control Panel in the Windows OS...

  • Page 84: Driver Installation

    Drivers & Utilities Driver Installation Double-click the My Computer icon (for WinXP only), and then double-click the CD icon. Insert the Device Drivers & Utilities + User’s Man- ual CD-ROM and the Notebook Driver Installa- tion application will run automatically. If you want to install the driver manually see “Manual Driver Installation”...

  • Page 85: Manual Driver Installation

    Drivers & Utilities Manual Driver Installation If you wish to install the drivers manually, click the Exit button to quit the Notebook Driver Installation application, then follow the manual installation procedure for each driver. The manual installation proce- dure begins with instructions on how to browse to the executable file; “Click Start (menu) > Run ..”. Feature Windows 2000 (SP4) Windows XP (SP1)

  • Page 86: Windows Xp & 2000 Professional

    Drivers & Utilities Windows XP & 2000 Professional This section covers driver and utility installation in- structions for Windows XP (Professional & Home) and Windows 2000 Professional. Windows XP Service Pack 1 New Hardware Found Make sure you install Windows XP Service Pack 1 (or a Windows XP version which includes Service If you see the message “New Hardware Found”...

  • Page 87: Chipset (Winxp & 2000)

    Drivers & Utilities Chipset (WinXP & 2000) Audio & Modem (Win2000) 1. Double-click CHIPSET from the Notebook 1. Double-click AUDIO from the Notebook Driver Installation menu . Driver Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Driv- (Browse..) to D:\Drivers\AUDIO\Setup.exe ers\CHIPSET\Setup.exe and click OK.

  • Page 88: Audio (Winxp)

    Drivers & Utilities Audio (WinXP) Modem (WinXP) 1. Double-click AUDIO from the Notebook 1. Double-click MODEM from the Notebook Driver Installation menu . Driver Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\AUDIO\Setup.exe (Browse..) to D:\Driv- and click OK.

  • Page 89: Lan (Winxp & 2000)

    Drivers & Utilities LAN (WinXP & 2000) Hot-Key (WinXP & 2000) 1. Double-click LAN from the Notebook Driver 1. Double-click AP-KEY from the Notebook Installation menu . Driver Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\LAN\Setup.exe and (Browse..) to D:\Drivers\AP-KEY\Setup.exe click OK.

  • Page 90: Touchpad (Winxp & 2000)

    Drivers & Utilities TouchPad (WinXP & 2000) Auto Mail Checker (WinXP & 2000) 1. Double-click TOUCHPAD from the Notebook 1. Double-click AUTOMAIL from the Notebook Driver Installation menu . Driver Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) >...

  • Page 91: Module Drivers

    Drivers & Utilities Module Drivers WLAN & Bluetooth Combo (WinXP & 2000) See the following pages for the driver installation procedures for any modules included in your pur- See install procedure in “Combo Module Blue- chase option. tooth Driver Installation (Win2000)” on page 8 - &...
  • Page 92 Drivers & Utilities 5 - 14...

  • Page 93: Bios Utilities

    BIOS Utilities Chapter 6: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return Setup and restore the Configuration: The Setup utility Setup Defaults with If your computer has never been set up, or you are making important changes...

  • Page 94: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- POST Screen duct a POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. 2.CPU type If there is a problem that prevents the system from booting, it will display a 3.Memory status...

  • Page 95: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 96: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 6 - 1 is usually present for a...

  • Page 97: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When Setup menus you select a heading, a new screen appears. Scroll through the features listed shown in this section on each screen to make changes to Setup.

  • Page 98: Main Menu

    BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 6 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:11:05] System Date: [09/22/2004] <Tab>, <Shift Tab>, or <Enter> selects field. IDE 0 [CD-ROM] IDE 1 [None] Installed memory 256 MB...

  • Page 99: Ide 0/1 (Main Menu)

    BIOS Utilities IDE 0/1 (Main Menu) Pressing Enter under opens the sub-menu to show the configuration of the ei- ther a CD Device or HDD that on the computer’s IDE Channels 0 or 1. Use the Auto (Type:) setting to have the items configured automatically for you. Installed memory (Main Menu) This item contain information on the system memory, and is not user config- urable.

  • Page 100: Advanced Menu

    BIOS Utilities Advanced Menu Figure 6 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Power Boot Exit Item Specific Help Setup Warning Setting items on this menu to incorrect values may cause your system to malfunction. System Information I/O Device Configuration Reset Configuration Data: [No]...

  • Page 101: I/O Device Configuration (Advanced Menu)

    BIOS Utilities I/O Device Configuration (Advanced Menu) The sub-menus under this item include options to configure the Serial port A (Serial Mouse), Serial port B (Infrared) and Parallel (Printer) port. These can be left to the default settings, however you may wish to use certain devices that require settings to be adjusted accordingly.

  • Page 102: Power On Beep (Advanced Menu)

    BIOS Utilities Power On Beep (Advanced Menu) Use this menu to enable/disable the single beep sound at the end of the POST. This item is “Disabled ” by default. Card Reader: (Advanced Menu) This option allows you to enable/disable support for the 7-in-1 Card Reader. and is “Enabled”...

  • Page 103: Security Menu

    BIOS Utilities Security Menu Figure 6 - 4 PhoenixBIOS Setup Utility Security Menu Main Advanced Security Security Boot Exit Item Specific Help Supervisor Password Is: Clear [E E nter] Set Supervisor Password Supervisor Password controls access to the Password on boot: [Disabled] setup utility.

  • Page 104: Password On Boot: (Security Menu)

    BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password (supervisor or user password) should be entered to boot the computer. If “Enabled” is selected, only users who enter a Password Warning correct password can boot the system (see the warning in the sidebar). The default setting is “Disabled”.

  • Page 105: Boot Menu

    BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 6 - 5 Main Advanced Security Exit Boot Boot Menu Item Specific Help Boot priority order: USB FDC: Y-E DATA USB-FDU-(USB) Keys used to view or IDE 0: TOSHIBA DVD-ROM SD-C2612- configure devices: PCI SCSI: FT TX Ary 1 Up and Down arrows...
  • Page 106 BIOS Utilities Boot devices usually are hard drives, floppy drives, and CD-ROMs. When you specify a device as a boot device on the Boot Menu, it requires the availability of an operating system on that device. Most home computers come with an operating system already installed on “Drive C:”. If you wish to boot from a CD-ROM you will need to add it to the boot order.

  • Page 107: Exit Menu

    BIOS Utilities Exit Menu Figure 6 - 6 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...
  • Page 108 BIOS Utilities 6 - 16...

  • Page 109: Upgrading The Computer

    Upgrading The Computer Chapter 7: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or prob- Warranty Warning lems you can contact your service representative for further help. Before you Please check with your begin you will need: service representative...

  • Page 110: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 111: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. Warranty Warning Turn the computer off, and turn it over. Please check with your Loosen screws service representative before undertaking any Release the battery, and lift the battery...

  • Page 112: Upgrading The Hard Disk Drive(S)

    Upgrading The Computer Upgrading the Hard Disk Drive(s) The hard disk drive(s) can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h) (see “Storage Options” on page B - HDD System Warning 3).
  • Page 113 Upgrading The Computer Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and remove screws Remove the bay cover Figure 7 - 2 HDD Bay Cover Removal Upgrading the Hard Disk Drive(s) 7 - 5...
  • Page 114 Upgrading The Computer Release the cable and lift the hard disk assembly up out off the computer. Remove screws in order to separate the bracket from the hard disk(s), and disconnect the cable Reverse the process to install a new hard disk(s). Figure 7 - 3 HDD Assembly Removal...

  • Page 115: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has four memory sockets for 200 pin Small Outline Dual In- line (SO-DIMM) - DDR-II (DDR2) - type memory modules (see “Memory” Contact Warning on page B - 2). The total memory size is automatically detected by the POST Be careful not to touch routine once you turn on your computer.
  • Page 116 Upgrading The Computer Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the arrows in Figure 7 - Figure 7 - 5 RAM Module Removal The RAM module will pop-up, and you can remove it. Pull the latches to release the second module if necessary.

  • Page 117: Upgrading The Optical (Cd/Dvd) Device(S)

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device(s) Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and remove screws , and remove the bay cover. Remove screw and use the screwdriver to push the optical device(s) out of the computer at point Figure 7 - 6 Removing the CD/...

  • Page 118: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a faster/new one you will need to contact your customer service representa- Warranty tive. We recommend that you do not do this yourself, since if it is done incor- The CPU is not a user rectly you may damage the processor or mainboard.

  • Page 119: Modules

    Modules Chapter 8: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the config- uration purchased. If you are unsure please contact your service representa- tive.

  • Page 120: The Wireless Lan & Bluetooth Modules

    Modules The Wireless LAN & Bluetooth Modules If your purchase option includes the any of the Wireless LAN modules and/or Wireless Device Bluetooth and Wireless LAN combination module, follow the information on Operation Aboard the following pages for instructions on installing the driver. Pay careful atten- Aircraft tion to the warnings concerning the use of wireless modules aboard aircraft, The use of any porta-...

  • Page 121: Mini Pci Wireless Lan Module

    Modules Mini PCI Wireless LAN Module Before installing the Wireless LAN driver, make sure that the optional Wireless Device WLAN module is on (the LED will be green). Operation Aboard Aircraft Use the WLAN module key combination Fn + F11 to toggle power to the The use of any porta- WLAN module.
  • Page 122 Modules CastleNet IPN2220 (802.11g) Wireless LAN Driver Installation (WinXP & 2000) 1. Insert the Wireless LAN CD-ROM into the CD/DVD drive. Network Connection 2. Click Start (menu) > Run ... 3. Navigate (Browse..) to D:\setup.exe and click OK. Windows 4. Click Next. Network Connec- tions control panel to...

  • Page 123: Bluetooth/Wlan Combo Module

    Modules Bluetooth/WLAN Combo Module Before installing the Bluetooth/WLAN driver, make sure that the optional Wireless Device Bluetooth module/WLAN is on. Use the Bluetooth module key combina- Operation Aboard tion Fn + F12 to toggle power to the Bluetooth module. Use the WLAN Aircraft module key combination Fn + F11 to toggle power to the WLAN module The use of any porta-...

  • Page 124: Combo Module Bluetooth Driver Installation (Winxp)

    Modules Combo Module Bluetooth Driver Installation (WinXP) 1. Insert the Bluetooth/WLAN Combo CD-ROM into the CD drive. 2. The program will run automatically. 3. Click Install Bluetooth Driver and click Next. 4. Click the button to accept the license agreement, then click Next. 5.

  • Page 125: Combo Module Wlan Driver Installation (Winxp)

    Modules Combo Module WLAN Driver Installation (WinXP) 1. Insert the Bluetooth/WLAN Combo CD-ROM into the CD drive. 2. The program will run automatically. Network Connection 3. Click Install WLAN Driver and click Next. 4. Click the button to accept the license agreement, then click Next. Windows 5.

  • Page 126: Tv Tuner

    Modules TV Tuner The optional TV Tuner allows you to watch TV, play music CDs, video con- TV Tuner Remote ference and capture still images and video on your PC. The TV Tuner comes with a remote control unit, and CDs containing AverTV The remote control unit provided with the op- Utility software), and InterVideo WinDVD 4 software.

  • Page 127: Installing The Avertv Utility Software

    Modules Installing the AverTV Utility Software (Win 2000) 1. Insert the AverTV Utility CD-ROM into the CD/DVD drive. PC Camera & TV 2. Click TV Utility Software. Tuner 3. Click Yes > Next > Next (click Continue Anyway/Yes if asked to con- If you have the optional tinue at any time).

  • Page 128: Installing The Intervideo Windvd 4 Software

    Modules (Win XP) 1. Insert the AverTV Utility CD-ROM into the CD/DVD drive. 2. Click TV Utility Software. 3. Click Yes > Next > Next (click Continue Anyway/Yes if asked to con- tinue at any time). 4. Click Finish. 5. Run the program from the Start > Programs/All Programs > AVer TV menu, and select the Aver TV program, or double-click the icon on the desktop.

  • Page 129: Pc Camera

    Modules PC Camera If your purchase includes the optional PC Camera you will need to install the PC Camera & TV device driver for it as indicated on the following pages (make sure you install Tuner the drivers in the order indicated in Table 5 - 1, on page 5 - If you have the optional TV Tuner included in...

  • Page 130: Pc Camera Audio Setup

    Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Taking Still Pictures (WinXP) You may take still pic- tures in the Windows Go to the Start menu and point to Settings (or just click Control Panel) and XP operating system click Control Panel, then double-click the Sounds &...
  • Page 131 Modules Figure 8 - 4 Audio Setup (Windows XP) PC Camera 8 - 13...

  • Page 132: Livecam

    Modules LiveCam LiveCam is a video viewer useful for general purpose video viewing and test- ing, and can capture video files to .avi format. Pre-Allocating File Space Run the LiveCam program from the Start > Programs/All Programs > You may pre-allocate Bs350u2 menu (it is recommended that you set the capture file before the the file size for the cap- capture process - see Set Capture File below).
  • Page 133 Modules Eliminating Screen Flicker If you find that the video screen in the LiveCam program is flickering, you can try to adjust the option from the Video Capture Filter options. Run the LiveCam program. Go to Options and scroll down to select “Video Capture Filter...”. Click the Flicker box and choose either 50Hz or 60Hz.

  • Page 134: Raid Configuration

    Modules RAID Configuration If you have included the optional RAID (Redundant Array of Independent Disks) configuration in your purchase option, this will allow you to use your hard disks in combination with Striping (RAID 0) or Mirroring (RAID 1) for fault tolerance and performance. Hard Disk Jumper Settings for RAID When using two hard disk in a RAID configuration in your computer, make sure to set the jumper on the slave hard disk to the cable select option in order for the...
  • Page 135 Modules RAID Level Description Identical drives reading and writing data in parallel to increase performance. RAID 0 implements a striped disk array and the RAID 0 data is broken into blocks and each block is written to a sepa- rate disk drive. Identical drives in a mirrored configuration used to protect data.

  • Page 136: Raid Setup

    Modules RAID Setup To create a disk array you will need to open the FastBuild Utility which is built into the BIOS if you have included the RAID option in your purchase config- uration. You will also need a blank floppy disk, and external USB floppy disk Figure 8 - 6 drive.
  • Page 137 Modules You can create two types of array as outlined in Table 8 - 1, “RAID Descrip- tion,” on page 8 - • RAID 0 - A Striped array for enhanced performance (1 or 2 drives) Setup Options • RAID 1 - A Mirrored array for data security (2 drives treated as one) What options are avail- able in “Optimize Ar- ray for”...
  • Page 138 Modules You will now need to format the array as if it were a single hard drive. Have a floppy disk ready and copy the RAID\Drivers folder from the Device Drivers & Utilities + User’s Manual CD-ROM (Navigate/Browse.. to D:Drivers\RAID\FASTTRAK) to the floppy disk. Startup from your operating system CD (Windows XP or Windows 2000 including Service Pack 4).

  • Page 139: Troubleshooting

    Troubleshooting Chapter 9: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 140: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 141: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g.

  • Page 142: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 143: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 144 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 145: Power

    Troubleshooting Power Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 146 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If hot. this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...

  • Page 147: Display

    Troubleshooting Display Problem Possible Cause - Solution Nothing appears The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + F4 screen. (see “Sleep Button” on page 4 - The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F8/F9 (see “Opening the LCD”...

  • Page 148: Boot Password

    Troubleshooting Boot Password Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact password. your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.

  • Page 149: Audio & Cd Device

    Troubleshooting Audio & CD Device Problem Possible Cause - Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel heard or the volume is in the Windows taskbar, or use the key combination Fn + F5 and F6 (see “Audio very low.

  • Page 150: Keyboard

    Troubleshooting Keyboard Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON. Check that Padlock mode is not enabled appear when typing. (see “LED Indicators” on page 1 - Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.

  • Page 151: Operation

    Troubleshooting Operation Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC adapter, press a key on the screen goes dark. the keyboard, or press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.

  • Page 152: Modules

    Troubleshooting Modules Problem Possible Cause - Solution Wireless LAN/ The modules are off. Check the LED indicator to see if the modules are on or off Bluetooth/ modules (see “LED Indicators” on page 1 - 6). If the LED indicator is off, then press the key cannot be detected.

  • Page 153: Interface (Ports & Jacks)

    Appendix A : Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your com- puter to communicate with external devices, connect to the internet etc. A - 1...

  • Page 154: Built-In Microphone

    Ports and Jacks Item Description Built-In Microphone The built-in microphone allows you to record on your computer DC-In Jack Plug the supplied AC adapter into this jack to power your computer. Serial Port Connect a serial type mouse to this port. Parallel Port Connect a parallel type printer to this port.

  • Page 155: Rj-11 Phone Jack

    Item Description RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g.

  • Page 156: Mini-Ieee 1394A Ports

    Item Description Mini-IEEE 1394a Ports This allows high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). IEEE 1394 The Mini-IEEE 1394a ports only support SELF POWERED IEEE 1394 devices. Line-In Jack The Line-In jack allows you to play audio sources through the computer’s speakers. S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD-capable PC to a Dolby AC-3 compatible receiver for “5.1”...

  • Page 157: Security Lock Slot

    Item Description Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. A - 5...
  • Page 158 A - 6...

  • Page 159: Specifications

    Appendix B: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly proces- sor types/speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release sched- ule.

  • Page 160: Processor Types

    Feature Specification Processor Types Intel® Pentium® 4 520/ 530/ 540/ 550/ 560 Processor with HT Technology LGA775 Package (775-pin) (90nm) 90 Nanometer Process Technology, 1024KB On-Die L2 Cache & 800MHz Front Side Bus - 2.8/ 3.0/ 3.2/ 3.4/ 3.6 GHz Core Logic Intel 915P + ICH6 Security...

  • Page 161: Storage Options

    Feature Specification Storage Options One External USB 1.44Mb Floppy Disk Drive One Changeable Primary 2.5" 9.5mm (h) Hard Disk Drive One Changeable Secondary 2.5" 9.5mm (h) Hard Disk Drive RAID (Option) Supports Serial ATA HDD RAID 0, RAID 1, HDD Fault Tolerance System (Optional) One Changeable Primary Optical Device Bay - 12.7 mm (h) for Optical CD/DVD Device Drive Options (see “Optional”...

  • Page 162: I/O Ports

    Feature Specification I/O Ports Four USB 2.0/1.1 Ports One S/PDIF Out Jack Two Mini-IEEE1394a Ports One RJ-11 Jack (Modem) One S-Video-Out Jack for TV & HDTV Output One RJ-45 Jack (Local Area Network) One Serial Port One DC-In Jack One Parallel Port (LPT1) Supporting ECP/EPP One CATV-In Jack (Functions with Optional One Infrared Transceiver (IrDA 1.1/FIR/SIR/ TV Tuner Module)

  • Page 163: Indicators

    Feature Specification Indicators LED Indicators (System Activity, Suspend/Power On/AC-In, Battery Charging/Battery Full, Num Lock, Caps Lock, Scroll Lock, Card Reader) Power Supports ACPI 2.0 Supports Resume from Alarm Management Supports Hibernate/Standby Modes Supports Resume from Modem Ring Supports Battery Low Sleep Power Full Range AC Adapter - AC-In 100~240V, 47~63Hz, DC Output 20V, 9A Easy Changeable 12-Cell Smart Lithium-Ion 6600mAH Main Battery...
  • Page 164 B - 6...

Table of Contents
