M-EOS-based platforms must operate with M-EOS 9.8.1 or later for McDATA Fabric Mode (in-
teropmode 2), or M-EOS 9.9.0 or later for Open Fabric Mode (interopmode 3).

WebTools compatibility

FOS 6.3 is supported with JRE 1.6.0 Update 13.
If the JRE 1.6.0 version is not Update 13, the DCFM server/client and B-series Element Manager
(WebTools) crashes on launch.
WebTools tunnel and TCP graphs support tool tips only for the first enabled TCP connection graph.
FOS feature compatibility in native connectivity modes
Some FOS features are not fully supported when operating in the native connectivity modes for
deployment with M-EOS-based products. All HP StorageWorks models supported by FOS 6.3.0x
support both interopmodes 2 and 3, with the exception of the 4/32 SAN Switch, 2408 FCoE
Converged Network Switch, and DC SAN Backbone Director or DC04 SAN Director with one or
more DC SAN Director Switch 10/24 FCoE Blades.
NOTE:
HP may not support all of these switches in this mode. For information about support in interopmodes
2 and 3, see HP StorageWorks Merging Fabrics Based on M-Series and B-Series Fibre Channel
Switches Application Notes , available at http://www.hp.com.
Table 5 specifies FOS feature support when operating in either interopmode 2 (McDATA Fabric Mode)
or interopmode 3 (Open Fabric Mode) with FOS 6.3.0b.
Table 5 Feature support in interopmodes 2 and 3
L2 FOS Hot Code Load
FOS Hot Code Load with FCR
Zone Activation Support
Traffic Isolation Zones
Frame Redirection (devices attached to FOS)
Frame Redirection (devices attached to M-EOS)
Frame Redirection over FCR
FCR Fabric Binding (route to M-EOS fabric with Fabric Binding)
L2 Fabric Binding
DCC policies
SCC policies
20
FOS features (supported in interopmode 0)
1
1
10
IM = interopmode
1
9
FOS 6.3.0b
IM 2 IM 3
Yes Yes
Yes Yes
11
Yes
Yes
Yes No
11
Yes
Yes
11
Yes
Yes
11
Yes
Yes
Yes Yes
Yes No*
No No
4
No*
Yes
