DC SAN Backbone and DC04 SAN Director blade support
FOS 6.3.0a is fully qualified and supports the DC Director blades listed in
Table 3 DC Director blade support matrix
Director blade
FC8-16
FC8-32
FC8-48
FC10-6
FC4-16IP (iSCSI blade)
FR4-18i (FCIP/FC Router blade)
FS8-18 (DC Switch Encryption FC blade)
FX8-24 (DC SAN Director Multiprotocol Extension
Blade)
FCOE10-24 (DC SAN Director Switch 10/24
FCoE Blade)
Power supply requirements for Director blades
Table 4
lists power supply requirements for Director blades to provide full redundancy (220 VAC
power is assumed).
Number of blades
Supported with FOS 6.0.0b or later with any mix, with up
to eight blades of each type on the DC SAN Backbone
Director. There are no intermix restrictions. The DC04 SAN
Director requires FOS 6.2.0a or later, and supports up to
four blades.
Not supported with the DC SAN Backbone Director or
DC04 SAN Director
Supported with FOS 6.0.0b or later, with a maximum of
four blades of this type on the DC SAN Backbone Director.
Up to eight FR4-18i blades can be installed if they are
used only for FC FastWrite or FCIP without routing on the
DC SAN Backbone Director. The DC04 SAN Director
requires FOS 6.2.0a or later, and supports up to four
blades.
Supported with FOS 6.2.0b or later, with a maximum of
four blades of this type on the DC SAN Backbone Director
or DC04 SAN Director
Supported with FOS 6.3.0x, with a maximum of two blades
per director. The DC SAN Director Switch 10/24 FCoE
Blade can be installed in the same chassis only with FC8-xx
and/or FC10-6 blades. It is not supported in the chassis
with any other blades.
HP StorageWorks FOS 6.3.0b Release Notes
Table
3.
17
