IMPORTANT:
Director blades must meet the minimum FOS levels to operate in the Director chassis. For example,
the FC8-32 is not supported in the 4/256 SAN Director with FOS 6.0.x.
Table 4 Power supplies required for blades in Director chassis
Director blade
FC4-16
FC4-32
FC4-48
FC8-16
FC8-32
FC8-48
FC10-6
FR4-18i (FCIP/FC Router blade)
FC4-16IP (iSCSI blade)
FS8-18 (DC Switch Encryption FC
Blade)
FX8-24 (DC SAN Director
Multiprotocol Extension Blade)
FCOE10-24 (DC SAN Director
Switch 10/24 FCoE Blade)
1
The FC blades in this row are the only ones supported in the DC SAN Backbone Director or DC04 SAN Director with 110
VAC power supplies.
2
110 VAC is not supported in either the DC SAN Backbone Director or DC04 SAN Director with these blades.
Fibre Channel Routing scalability
For the latest information about Fibre Channel Routing (FCR) scalability support, see the HP
StorageWorks SAN Design Reference Guide, available at:
http://www.hp.com/go/sandesignguide
18
4/256 SAN Director
Two power supplies
Four power supplies
Four power supplies
Not supported
DC SAN Backbone Director and
DC04 SAN Director
1
Two power supplies
2
Two power supplies
Two power supplies. The FC4-16IP
blades are not supported in the DC
SAN Backbone Director or DC04
2
SAN Director.
Two power supplies. For the DC
SAN Backbone Director with three
or more FS8-18 blades, (2+2) 220
VAC power supplies are required
for redundancy. For one or two
FS8-18 blades, only two power
supplies are required for
redundancy. For the DC04 SAN
Director, only two 220 VAC power
supplies are required for
redundancy with any number of
FS8-18 blades.
For the DC SAN Backbone Director
or DC04 SAN Director, only two
220 VAC power supplies are
required for redundancy with
2
FX8-24 blades.
