Chapter 8
3. With the help of at least one other person, lift the server by its four
handles. Move the server between the extended slide members, so that the
slides are underneath the server's handles on each side. See Figure 8-8.
2. Fasten slides to
server with screws
(four screws per slide)
Figure 8-8. Mounting the Server on the Slides
4. Lower the server onto the slide members. The server's handles will
support the server on the slides for now. Adjust the server's position on the
slides so that the mounting holes on the side of the chassis line up with
the screw holes in the slide members.
5. Fasten the server to the slides with screws.
84
Mounting the Server in the Rack
1. Move server onto
slides.
Handles
