Chapter 4
Installing Mass Storage Devices
Filler Plug
Hot Swap Drive
Figure 4-1. Hot Swap Drive and Filler Panel
2. On the drive, press the locking latch in and pull the ejector handle out as
far as it can go, as shown in Figure 4-2.
CAUTION
Be careful when you open the ejector handle. Extreme force
can snap off the handle.
29
