HP D5970A - NetServer - LCII Installation Manual page 31

Chapter 3
tools or jewelry. Disconnect any telephone cables to avoid
exposure to shock hazard from telephone ringing voltages.
3. Remove the two Torx screws at the front of the cover, then slide the cover
back approximately one half-inch. See Figure 3-2.
1. Remove screws
Figure 3-2. Unfastening the Cover and Sliding It Back
4. Lift off the cover. See Figure 3-3.
Opening and Closing the HP NetServer
2. Pull back cover
1/2 inch
23
