8 Mounting the Server in the Rack

Introduction

This chapter tells how to mount the HP NetServer in a HP System/E or System/U
rack. The illustration below shows the characteristics of the System/E and
System/U racks. If you have the older HP Systems rack, see Chapter 13 for
instructions. (If you are mounting the server in a non-HP rack, refer to the
separate rack-mounting guide for third-party racks. It is packed in the accessories
tray in the HP NetServer's shipping box.)
Figure 8-1. HP System/E and System/U Rack Features
a
b
Characteristics of
c
System/E and
System/U Racks:
a. 5-Cornered Columns
d
b. Full Panel Vent
c. "HP Rack System/E" or
"HP Rack System/U"
Name Plate
d. Numbered EIA Units
e. Anti-Tip Foot Extends
Out Front or Back
e
