Chapter 5
5. Align the notches on the DIMM with the notches on the socket.
6. Hold the DIMM so that the front edge faces straight down into the
connector (at a 90 angle to the memory board).
7. Insert the DIMM carefully into the desired slot. The retaining clips will
grasp the DIMM automatically if it is inserted properly.
CAUTION Do not rock the EDO DIMM into place, but apply firm and
even pressure. If a gap exists between the retaining clips and
the DIMM module, remove the module and repeat steps 5-7.
8. Repeat steps 3-7 to install DIMMs in the DIMM slot sequence listed in
Figures 5-4 and 5-5 until you have installed all DIMMs for your memory
configuration.
9. Replace the memory board in the server. See "Removing and Replacing a
Memory Board."
Figure 5-11. Installing a DIMM Module
Installing Additional Memory
45
