Adapter Specifications
2. Average A-Weighted sound power levels (LWAd) and average bystander position A-Weighted sound pressure levels (LpAm)
in a 23°C ambient environment, measured in accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO
9296 (ECMA 109). Acoustic noise levels are maximum measurements with four fans installed.
3. All temperature ratings shown are for sea level. An altitude derating of 1°C per 300 m (1.8°F per 1,000 ft) to 2000 m (6500 ft)
is applicable. No direct sunlight allowed.
4. The type and number of options installed can limit the upper limit.
5. System performance may be reduced if operating with a fan fault above 30ºC (86ºF).
Adapter Specifications
Table A-2
Inline Network Adapter Specifications
Specification
Copper Gigabit Ethernet Specifications
IEEE standard
Full duplex and half duplex
Autonegotiation
Data transfer rate
Ports
General Technical Specifications
Interface standard
Size
PCI Express card type
Cisco Wide Area Virtualization Engine 574 Hardware Installation Guide
A-4
Table A-2
describes the inline network adapter technical and general
specifications.
Description
Gigabit Ethernet, 1000BASE-T
Fast Ethernet, 100BASE-T
Ethernet, 10BASE-T
Supports both half-duplex and full-duplex operation in all operating
speeds
Autonegotiates between full-duplex and half-duplex operations and
between 1000-Mbps, 100-Mbps, and 10-Mbps speeds
1000-Mbps, 100-Mbps, and 10-Mbps speeds per port in half-duplex
mode
2000-Mbps, 200-Mbps, and 20-Mbps speeds per port in full-duplex
mode
4-Port Inline Adapter: 4 × RJ-45 socket connectors
2-Port Inline Adapter: 2 × RJ-45 socket connectors
PCI-Express Base Specification Revision 1.0
PCI Short add in card: 6.6 × 4.4 in. (167.6 × 111.2 mm)
×4
Appendix A
WAVE-574 Hardware Specifications
OL-17738-01
