Replacing a Hard Disk Drive

Replacing a Hard Disk Drive
Note
Caution
Step 1
Step 2
Step 3
Step 4
Cisco Wide Area Virtualization Engine 574 Hardware Installation Guide
4-6
For information about connecting cables to the Cisco WAVE Inline Network
Adapter, see Chapter 5, "WAVE Inline Network Adapter."
The WAVE appliance supports as many as two 3.5-inch (Large Form Factor)
SATA hard drives.
When replacing hard drives to the WAVE appliance, observe the following general
guidelines:
The system automatically sets all drive numbers.
•
If only one hard drive is used, install it in the bay with the lowest drive
•
number.
Drives must be the same capacity to provide the greatest storage space
•
efficiency when drives are grouped together into the same drive array.
All hard disk drives being used in the appliance must be identical.
To maintain proper system cooling, do not operate the appliance for more than 10
minutes without either a hard disk drive or a filler panel installed in each bay.
To replace a hard disk drive in a bay, follow these steps:
Review the information in the
page 2-2 and the "Safety Guidelines" section on page
Make sure that the chassis cover is in place and fully closed.
Power down the device and and disconnect the power cord and all external cables.
Slide the latch and then pull out the handle (see
Chapter 4 Installing Hardware Options for the WAVE-574
"Safety Warnings and Cautions" section on
Figure
2-3.
4-4).
