Completing the Installation

Caution
Step 1
Step 2
Step 3
Step 4
Step 5
Completing the Installation
Step 1
Step 2
Step 3
Caution
Cisco Wide Area Virtualization Engine 574 Hardware Installation Guide
4-2
Do not operate the WAVE appliance for long periods with the access panel open
or removed. Operating the WAVE appliance in this manner results in improper
airflow and improper cooling that can lead to thermal damage.
To remove the appliance covers, follow these steps:
Review the information in the
page 2-2 and the "Safety Guidelines" section on page
Power off the appliance and all attached devices and disconnect all external cables
and power cords.
Remove the WAVE appliance from the rack.
Loosen the captive T-15 Torx thumbscrew that secures the access panel to the
WAVE appliance.
Slide the access panel toward the rear of the WAVE appliance, then lift it from the
WAVE appliance.
To complete your installation after you have installed an inline adapter, hard drive,
or memory, follow these steps:
Lower the access panel onto the WAVE appliance and then slide the access panel
toward the front of the WAVE appliance.
Tighten the captive T-15 Torx thumbscrew that secures the access panel to the
WAVE appliance.
Install the appliance in a rack.
For complete rack installation and removal instructions, see
the WAVE-574."
Install the appliance only in a rack cabinet with perforated doors.
Chapter 4 Installing Hardware Options for the WAVE-574
"Safety Warnings and Cautions" section on
2-3.
Chapter 3, "Installing
OL-17738-01
