Chapter 5 WAVE Inline Network Adapter

Ports and LED Indicators

Figure 5-2 4-Port Inline Network Adapter Port Numbering and LEDs
W1
W1 Port WAN1; Group 1 WAN interface
W0 Port WAN0; Group 0 WAN interface
OL-17738-01
prevents the WAVE appliance from becoming a single point of failure and allows
traffic to continue to flow between the router and the client while it passes through
an unresponsive WAVE appliance without being processed.
For more information about configuring the inline network adapter, see the Cisco
Wide Area Application Services Configuration Guide.
Figure 5-2 shows the 4-port inline network adapter port numbers, interface
designations, and LEDs. The 2-port adapter is similar, but has only two ports and
two sets of LEDs.
L1 W0
The inline network adapter has three LEDs that correspond to each port (the W1
LEDs correspond to Port W1, and so forth).
Cisco Wide Area Virtualization Engine 574 Hardware Installation Guide
W1 L1 W0 L0
L0
L1 Port LAN1; Group 1 LAN interface
L0 Port LAN0: Group 0 LAN interface
Table 5-1
Ports and LED Indicators
LINK/ACT
100
BYPASS
1000
describes the LEDs.
